AU-G90X

SERVICE MANAUL

Page 2

AU-GQO

CAUTION

1. The symbols, UL, CSA, SA, BS, UK, EU, AS and XX (EXPORT) on
the parts list and the schematic diagram mean followings respectively.
UL.... ............. Manufactured for U.S.A market.

(Underwriters Laboratories approved model.)
CSA .................... Manufactured for Canadian market.

SA .......... Manufactured for South African market.
BS, UK .. Manufactured for United Kingdom market.
EU Manufactured for European market.

AS.... .. Manufactured for Australian market.

XX (EXPORT) .. Standard Version.
NON MARK ........ Common Parts.

2. Some printed circuit boards are not supplied as the assembled.
To separate these in this service manual, the stock Nos are not in-
dicated at the ends of the board names. However, the individual parts
on the circuit boards are provided by orders.

3. Since some of capacitors and resistors are omitted from parts lists
in this service manual, refer to the Common Parts List for capacitors
& resistors, which was issued on February 1983.

4. Abbreviations in this service manual are as follows.

oAbbreviations List

C.R. : Carbon Resistor E.B.L. : Low Leak Bi-Polar

S.Fi. : Solid Resistor Electrolytic Capacitor

Ce.R, : Cement Resistor Ta.C. : Tantalum Capacitor

MR : Metal Film Resistor F.C. : Film Capacitor

F.R. : Fusing Resistor M.P. : Metalized Paper Capacitor

N.I.R. : Non-Inflammable Resistor PC. : Polystyrene Capacitor

A.Fl. : Array Resistor G.C. : Gimmic Capacitor

C.C. : Ceramic Capacitor AC : Array Capacitor

C,T, : Ceramic Capacitor. V.R, : Variable Resistor
Temperature Compensation S,V.R, : Semi Variable Resistor

EC, : Electrolytic Capacitor SW. : Switch

E.L. : Low Leak Electrolytic Chip R. : Chip Resistor
Capacitor Chip C. : Chip Capacitor

EB. : Bi-Polar Electrolytic
Capacitor
