Sansui AM 90 Service Manual

Page 2

1. OTHER PARTS

0Front View
Parts List
Parts No. Stock No. Description Parts No. Stock No. Description
1 47560700 Front Panel Assy (with Push 12 46556400 Push SW.,
Knob 1-1, PHONOoTUNERo LOUDNESS-EQUALIZER
AUX/DA-TAPE) 13 47538200 Push Knob, SPEAKERS
2 47380300 Slide Knob, GRAPHIC EOUALIZER 14 46361000 Push SW., SPEAKERS
3 46834600 250k9x2 Slide V.R., GRAPHIC 15 24306200 Jack, PHONES
EOUALIZER 16 47560200 Push Knob, TAPEZ
4 46396700 Push SW., PHONO-TUNER- 17 46556300 Push SW1, TAPE-2
AUX/DA-TAPE-I 18 46176900 LED TLS-123 (Red), GRAPHIC
5 47560400 Bonnet (XX, UL, CSA) EQUALIZER - _
47560500 Bonnet (EU, BS, A5) or 46470200 LIED SEL221OS (Red), GRAPHIC
6 47557200 Knob, MASTER VOLUME (Right) EQUALIZER
7 47557100 Knob, MASTER VOLUME (Left) 19 46838700 Jack, MIC
8 46555900 150kfliBI><2 V.R., MASTER 20 07779920 Knob, MIC
VOLUME 21 46834700 20k0iA) V.R., MIC
9 47157800 Push Knob, POWER 22 47491000 Side Panel (Right)
A10 46364300 Push SW., POWER 23 47490910 Side Panel (Left)
11 47560300 Push Knob,
LOUDNESS-EOUALIZER

2, PACKING LIST

3. ACCESSORY LIST

Parts No. Stock No. Description Pans No. Stock No. Description
1 09453300 Vinyl Cover 46952400 Operating Instruction
2 47187830 Styrofoam Packing 46953700 Operating Sheet
3 47558100 Carton Case
