Extracted text from Rotel RX 975 OM (Ocr-read)
Page 1
2 RX-975 AM/FM Stereo Receiver WARNING: There are no user serviceable parts inside. Refer all servicing to qualified service personnel. WARNING: To reduce the risk of fire or electric shock, do not expose the unit to moisture or water. Do not allow foreign objects to get into the enclosure. If the unit is exposed to moisture, or a foreign object gets into the enclosure, immediately disconnect the power cord from the wall. Take the unit to a qualified service person for inspection and necessary repairs. Read all the instructions before connecting or operating the component. Keep this manual so you can refer to these safety instructions. Heed all warnings and safety information in these instruc- tions and on the product itself. Follow all operating instruc- tions. Clean the enclosure only with a dry cloth or a vacuum cleaner. You must allow 10 cm or 4 inches of unobstructed clearance around the unit. Do not place the unit on a bed, sofa, rug, or similar surface that could block the ventilation slots. If the component is placed in a bookcase or cabinet, there must be ventilation of the cabinet to allow proper cooling. Keep the component away from radiators, heat registers, stoves, or any other appliance that produces heat. The unit must be connected to a power supply only of the type and voltage specified on the rear panel of the unit.NOTE TO CATV SYSTEM INSTALLER: Call the CATV system or antenna installers attention to Ar- ticle 820-40 of the NEC. This provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the pint of cable entry as practical. See installa- tion diagram. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause interference to radio or TV commu- nications. There is no guarantee that interference will not occur in a particular installation. If this equipment does cause in- terference to radio or television reception, which can deter- mined by turning the equipment off and on, try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the unit and the televi- sion tuner. - Connect the unit to an AC power outlet on a different elec- trical circuit. - Consult your authorized Rotel retailer for assistance. Connect the component to the power outlet only with the sup- plied power supply cable or an exact equivalent. Do not modify the supplied cable in any way. Do not attempt to defeat ground- ing and/or polarization provisions. Do not use extension cords. Do not route the power cord where it will be crushed, pinched, bent at severe angles, exposed to heat, or damaged in any way. Pay particular attention to the power cord at the plug and where it exits the back of the unit. The power cord should be unplugged from the wall outlet if the unit is to be left unused for a long period of time. Immediately stop using the component and have it inspected and/or serviced by a qualified service agency if: - The power supply cord or plug has been damaged. - Objects have fallen or liquid has been spilled into the unit. - The unit has been exposed to rain. - The unit shows signs of improper operation - The unit has been dropped or damaged in any way Place the unit on a fixed, level surface strong enough to sup- port its weight. Do not place it on a moveable cart that could tip over.
Page 2
3 Figure 1: Controls and ConnectionsEnglish
