Rotel RX 150A OM

Page 1

OPERATING MANUAL

RX-l50A

Page 2

INTRODUCTION

We would like to take this opportunity to thank you for purchasing our
Stereo Receiver. With the high quality design and workmanship that goes into
making this equipment, you can be assured of its flawless performance tor

many years to come.

We have fitted everyrcontrol and feature you could conceivably need.
Designed for both versatility and ease of operation, this piece of equipment
will add professional studio flexibility to your Hi-Fi sound center. The per-
formance is exceptional, it will allow you to experience true high fidelity as
never before. its full and natural stereophonic reproduction offers you musical
entertainment approaching that of live performances. We sincerely hope you
will treasure this professional equipment. In order to obtain the maximum use
out of your unit, please read the following pages of this Operating Manual

carefully.

Do not attempt to operate the unit until you have made all the necessary

connections.

SPECIAL FEAT URES

7)

9)

10)

11)

All Silicon Output Transistors.
Illuminated Dial Pointer with Stereo indicator feature.
Illuminated AM/FM Signal Strength Tuning Meter.

Speaker Switches for simultaneous or independent operation of two

pairs of stereo speaker systems.
Tape Monitor Switch for convenient tape recorder play back and
monitoring,

Tone Controls for Bass and Treble offer easy and accurate tone ad-

justment.

Balance Control to insure perfect stereophonic effect regardless of

taulty room acoustics, poor recording or unmatched component outputs.

Connections for two tape recorders, so that you may dubb from one

to the other.

Connections for two record players, one for magnetic cartridge and

one for ceramic or crystal cartridge.
Front Panel Stereo Headphone Jack for easy use.

Handsome Wood Cabinet.
