OPERATING MANUAL

I F2 :31- E u
RT-620

Page 2

INTRODUCTION

We would like to take this opportunity to thank you for purchasing
our ROTEL RT-620 AM/FM STEREO TUNER. In RT-620 you have
the finest equipment available in the Hi-Fi components field. With the
quality workmanship that goes into making the RT-620, you can be
assured of its flawless performance for many years to come.

The RT-620 is equipped with every conceivable control and feature
any demanding audiophile ever hopes of having on his unit. The RT-620
was designed for both the versatility and ease of operation. It will
add professional studio flexibility to you present music center.

The performance of RT-620 is exceptional; it will allow you to
experience true high fidelity as never before. Its full and natural stereo-
phonic reproduction offers you musical entertainment rivaling that of
live performances. We sincerely hope you will treasure this professional
equipment.

In order to obtain the maximum use out of your unit, please read
all of the following pages of this Operation Manual carefully.

Do not attempt to operate the unit until you have made all the con-
nections as specified in this Manual.

SPEGIAL FEATURES

1)

2)

3)
4)
5)
6)
7)
8)
9)
10)

FM Section: FET Front-End,
4-Gang Variable Capacitor,
2-Stage RF Amplifier,
Ceramic Filters,
Variable Muting Control.

AF Section: 3-Gang Variable Capacitor,
1-Stage RF Amplifier,
Ceramic Filters.

Variable AM and FM Output Levels.

Noise Filter.

AM-FM Dual Illuminated Tuning Meter.

Stereo Indicator Light.

Illuminated Dial Pointer.

Control Knobs: Variable Muting Level and Tuning.

Push Buttons: Power, AM, FM, FM Stereo, Noise Filter and Muting.

Handsome Wood Cabinet.
