Rotel RSP 985 OM
This is the 27 pages manual for Rotel RSP 985 OM.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Rotel RSP 985 OM (Ocr-read)
Page 1
SURROUND SOUND PROCESSOR RSP-985 2 CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT. INSERT FULLY. APPLICABLE FOR USA, CANADA OR WHERE APPROVED FOR THE USAGE ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU AU FOND. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: There are no user serviceable parts inside. Refer all servicing to qualified service personnel. WARNING: To reduce the risk of fire or electric shock, do not expose the unit to moisture or water. Do not allow foreign objects to get into the enclosure. If the unit is exposed to moisture, or a foreign object gets into the enclosure, immediately disconnect the power cord from the wall. Take the unit to a qualified service person for in- spection and necessary repairs. Read all the instructions before connecting or operating the component. Keep this manual so you can refer to these safety instructions. Heed all warnings and safety information in these instructions and on the product itself. Follow all operating instructions. Clean the enclosure only with a dry cloth or a vacuum cleaner. You must allow 10 cm or 4 inches of unobstructed clearance around the unit. Do not place the unit on a bed, sofa, rug, or similar surface that could block the ventilation openings. If the unit is placed in a bookcase or cabinet, there must be ventilation of the cabinet to allow proper cooling. Keep the component away from radiators, heat registers, stoves, or any other appliance that produces heat. The unit must be connected to a power supply only of the type and voltage specified on the rear panel of the unit. Connect the component to the power outlet only with the supplied power sup- ply cable or an exact equivalent. Do not modify the supplied cable in any way. Do not attempt to defeat grounding and/or polarization provisions. The cable should be connected to a 2-pin polarized wall outlet, matching the wide blade of the plug to the wide slot of the receptacle. Do not use extension cords. Do not route the power cord where it will be crushed, pinched, bent at severe angles, exposed to heat, or damaged in any way. Pay particular attention to the power cord at the plug and where it exits the back of the unit. The power cord should be unplugged from the wall outlet if the unit is to be left unused for a long period of time. Immediately stop using the component and have it inspected and/or serviced by a qualified service agency if: ¥ The power supply cord or plug has been damaged. ¥ Objects have fallen or liquid has been spilled into the unit. ¥ The unit has been exposed to rain. ¥ The unit shows signs of improper operation ¥ The unit has been dropped or damaged in any way Place the unit on a fixed, level surface strong enough to support its weight. Do not place it on a moveable cart that could tip over. This symbol is to alert the user to the presence of uninsulated dangerous voltages inside the product's enclosure that may constitute a risk of electric shock. This symbol is to alert the user to important operating and maintenance (service) instructions in this manual and literature accompanying the product.
Page 2
RSP-985 3 Figure 1 Ð Controls and Connections 23 4 TUNER 1 STANDBY SURROUND SOUND PROCESSOR RSP-985 5.1 CH INPUT WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE. REMOTE SENSOR MASTER VOLUME DIGITAL PRO LOGIC 3,4 1,2 MONO 2 CH BASS TREBLE MODE TAPE MONITOR 5.1 CH INPUT VIDEO 4 VIDEO 3 VIDEO 2 VIDEO 1 TUNER CD RECORDINGVIDEO 4 VIDEO 3 VIDEO 2 VIDEO 1 TUNER CD LISTENING OUTPUT TV MONITOR OUTPUT INPUT S-VIDEO INPUT S-VIDEO OUTPUT V 1 V 2 V 3 CD TUNER CD 2VIDEO 34 TAPE MONITOR IN OUT ZONE 2OUT FRONT REAR CENTER SUBW EXTENSIONIN OUT L RPOWER MODE V 4 V 2 V 3 V 4 REMOTE EXTERNAL IN DIGITAL INPUT V 1 V 2 V 3 CD TUNER 5.1 CH OUTPUT SWITCHED AC 4A 500W MAX VIDEO 4 IN SURROUND SOUND PROCESSOR MODEL NO. RSP-985POWER CONSUMPTION: 45W RSP-985 CAUTIONRISK OF ELECTRIC SHOCK DO NOT OPEN AVIS: RISQUE DE CHOC ELECTRIQUEÐNE PAS OUVRIR DOLBY DTS THX VIDEO 1 2 12 21 3 4 6 7 8 9 5 10 11 22 13 15 16 19 23 19 26 24 20 17 25 14 18
