Rotel RDV 995 OM
This is the 58 pages manual for Rotel RDV 995 OM.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Rotel RDV 995 OM (Ocr-read)
Page 1
2 CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT. INSERT FULLY. APPLICABLE FOR USA, CANADA OR WHERE APPROVED FOR THE USAGE ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU AU FOND. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: There are no user serviceable parts inside. Refer all servicing to qualified service personnel. WARNING: To reduce the risk of fire or electric shock, do not expose the unit to moisture or water. Do not allow foreign objects to get into the enclosure. If the unit is exposed to moisture, or a foreign object gets into the enclosure, immedi- ately disconnect the power cord from the wall. Take the unit to a qualified ser- vice person for inspection and necessary repairs. Read all the instructions before connecting or operating the component. Keep this manual so you can refer to these safety instructions. Heed all warnings and safety information in these instructions and on the product itself. Fol- low all operating instructions. Clean the enclosure only with a dry cloth or a vacuum cleaner. You must allow 10 cm or 4 inches of unobstructed clearance around the unit. Do not place the unit on a bed, sofa, rug, or similar surface that could block the ventilation slots. If the compo- nent is placed in a bookcase or cabinet, there must be ventilation of the cabinet to allow proper cooling. Keep the component away from radiators, heat registers, stoves, or any other appliance that produces heat. The unit must be connected to a power supply only of the type and voltage specified on the rear panel of the unit. Connect the component to the power outlet only with the supplied power supply cable or an exact equivalent. Do not modify the supplied cable in any way. Do not attempt to defeat grounding and/or polarization provisions. Do not use extension cords. Do not route the power cord where it will be crushed, pinched, bent at severe angles, exposed to heat, or damaged in any way. Pay particular attention to the power cord at the plug and where it exits the back of the unit. The power cord should be unplugged from the wall outlet if the unit is to be left unused for a long period of time. Immediately stop using the component and have it inspected and/or serviced by a qualified service agency if: ¥ The power supply cord or plug has been damaged. ¥ Objects have fallen or liquid has been spilled into the unit. ¥ The unit has been exposed to rain. ¥ The unit shows signs of improper operation ¥ The unit has been dropped or damaged in any way Place the unit on a fixed, level surface strong enough to support its weight. Do not place it on a moveable cart that could tip over. This equipment has been tested and found to comply with the limits for a Class B digital de- vice, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gene rates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio com- munications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television recep- tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2.DANGER: Visible laser radiation when open and interlock failed or bypassed. Avoid direct exposure to beam. 3.CAUTION: Do not open the top cover. There are no user serviceable parts inside the player; leave all servicing to qualified service personnel. WARNING! To reduce the risk of electrical shock, fires, etc.: 1. Do not remove screws, covers or cabinet. 2. Do not expose the unit to rain or moisture. 3. Do not touch the power cord or plug with wet hands. RDV-995 DVD Player
Page 2
3 OPN/ CLS VSSTHEATER POSITIONTV POWER DV D POWER RR-DV92 SUB TITLE AUDIO DIGEST SHIFT CANCEL TIME CHOICEPLAY MODE DISPLAY PLAY PAUSE STOP TITLE ENTER MENU RETURN STROBE ZOOM ANGLE TV/VIDEO 123 456 789 10 SLOWTV VOLTV CH 0 +10 + - + - + - 1 2 3 4 5 6 7 8 9 10 11 12VSS button OPEN/CLOSE button SUBTITLE – DIGEST button AUDIO – STROBE button Numeric buttons SLOW button SHIFT button PLAY MODE – CANCEL button BACK SKIP – SEARCH button PAUSE button TITLE button CURSOR ( UP, DOWN, LEFT, RIGHT) button 13 14 15 16 17 18 19 20 21 22 23 24 25 26Infrared output window THEATER POSITION button DVD POWER – TV POWER button TV / VIDEO button ANGLE – ZOOM button TV CH button TV VOL button RETURN – CHOICE button DISPLAY – TIME button FORWARD SKIP – SEARCH button PL AY button ENTER button STOP button MENU button Figure 1: RR-DV92 Remote Control 1 VSS button Turn on/off the simulated Virtual Surround Sound system. 2 OPEN/CLOSE button Opens and closes the disc tray. 3 SUBTITLE Ð DIGEST button Used to activate the on-screen subtitle selection display and to turn the subtitle on or off (for DVD VIDEO). Pressing this button while holding down the SHIFT button displays beginning scenes of each title, chapter or track on the TV screen (for DVD VIDEO/Video CD). 4 AUDIO Ð STROBE button Used to activate the on-screen Audio display to select the audio options (for DVD VIDEO/Video CD). Pressing this button while holding down the SHIFT button activates the Strobe function, which displays nine continuous still pictures (for DVD VIDEO/Video CD). 5 Numeric buttons Used to select a title or track number, to enter a time for the Time search, and a chapter number for the Chapter search. Also used to select a TV channel in conjunc- tion with the SHIFT button. 6 SLOW button Used for slow-motion video playback functions (for DVD VIDEO/Video CD). 7 SHIFT button Used together with other buttons to activate their second functions. 8 PLAY MODE Ð CANCEL button Displays an on-screen display for controlling the advanced playback functions. Pressing this button while holding down the SHIFT button cancels the last selection of the pro- gram. 9 Back SKIP Ð SEARCH button Skips back a chapter, title or track. Also used for the page selection of a menu screen (for DVD VIDEO/Video CD). Holding down this button during playback reverses playback rapidly. Pressing the button while holding down the SHIFT button during playback also reverses play- back rapidly. If you press the button while hold- ing down the SHIFT button during rapid reverse playback, the speed increases. 10 II (PAUSE) button Pauses playback. 11 TITLE button Displays the title menu of a DVD Video disc on the TV screen. 12 p/q/u/t Cursor buttons Used to select an item from a menu or on-screen display, or to change the setting of an item in the on-screen display. 13 Infrared signal-emitting window Point this window toward the remote sensor on the front panel when pressing buttons. 14 THEATER POSITION button Activates an on-screen display to select from one of four picture character options (for DVD VIDEO/ Video CD). 15 DVD POWER Ð TV POWER button Turns the RDV-995 on or off (standby). Pressing this button while holding down the SHIFT button turns the TV on or off. 16 TV/VIDEO button Switches the TV input mode. 17 ANGLE - ZOOM button Changes camera angles during playback of a DVD VIDEO disc containing multiple camera angles. Pressing this button while holding down the SHIFT button zooms in the picture (for DVD VIDEO/ Video CD). 18 TV CH button Changes the TV channels. 19 TV VOL button Adjusts the TV volume. 20 RETURN Ð CHOICE button Returns to the previous menu (for DVD VIDEO/ Video CD). Pressing this button while holding down the SHIFT button activates the on-screen Preference display. 21 DISPLAY Ð TIME button Displays the status information (only for DVD disc) or the time information (for any disc types). When the time information appears, pressing this but- ton while holding the SHIFT button changes the time mode. 22 FORWARD SKIP Ð SEARCH button Skips forward a chapter, title or track. Also used for the page selection of a menu screen (for DVD VIDEO/Video CD). Holding down this button during playback advances playback rapidly. Pressing the button while holding down the SHIFT button during playback also reverses play- back rapidly. If you press the button while hold- ing down the SHIFT button during rapid reverse playback, the speed increases. 23 u PLAY button Starts playback. Also used as a SELECT button for PBC of Video CDs. 24 ENTER button Used to select functions or controls a menu or on- screen display. 25 n (STOP) button Stops playback. Also used to erase all the pro- grammed tracks for the program play. 26 MENU button Displays a DVD menu on the TV screen. English
