ROLAND MC 307
This is the 24 pages manual for ROLAND MC 307.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from ROLAND MC 307 (Ocr-read)
Page 1
MC-307 JAN, 2000 2 LOCATION OF CONTROLS/パネル配置図 /パネル配置図 /パネル配置図 /パネル配置図panel.eps LOCATION OF CONTROLS PARTS LIST/パネル配置図パーツリスト /パネル配置図パーツリスト /パネル配置図パーツリスト /パネル配置図パーツリスト NO. PART CODE PART NAME DESCRIPTION ~01343112 J R-KNOB J R-KNOB MF BLK/LCG 01903489 9M/M ROTARY POTENTIOMETER EVJY10F03B14 01670312 9M/M ROTARY POTENTIOMETER EVUJDDFL3B14 W/CLICK&NUT 01670289 9M/M ROTARY POTENTIOMETER EVUJDCFL3B14 W/NUT 22485303 D R-KNOB L BLK 248-303 01905467 ROTARY ENCODER EVE GC1 F20 24B ~01340290 TACT SWITCH EVQ11A H=5.0 ~01787045 LED(ORANGE) SLR-325DCT31 01670478 F C-KEYTOP SX3H CLR 01670489 F C-KEYTOP SX2H CLR 01670490 F C-KEYTOP SX1H CLR 00560745 LED (GREEN) SLR-325MCT31 01670490 F C-KEYTOP SX1H CLR 01670512 F C-KEYTOP SX1H BLK ~02011856 LED SLR-56DCT32 01904134 F C-KEYTOP MX4H CLR 01904145 F C-KEYTOP MX2H CLR 01904156 F C-KEYTOP MX2H BLK ~00894645 TACT SWITCH SKECAF WITHOUT LED 01904412 KEYTOP RESET 00901423 KEYTOP FWD/RWD(WHIT GREY) 00901390 KEYTOP STOP(WHIT GREY) 00901401 KEYTOP PLAY(WHIT GREY) 00901412 KEYTOP REC(RED) 01904101 J S-KNOB L BLK/LCG 01903778 100M/M SLIDE POTENTIOMETER RSA0N1144(50KB) 01904089 LED LENS ~01011656 LED (RED) SLR-332VR3F 00785812 LED SPACER LH-5S-3 (3MM HIGHT) 12169391 LED SPACER LH-5S-10 01012078 LED (GREEN) SLR-332MG3F 1 1 1 1 12169391 LED SPACER LH-5S-10 00127367 LED (RED/GREEN) SPR-39MVW 01906623 LED SPACER LH-36-8.5 01907901 LED LNJ482YKXXE 01343090 LED SPACER 01348990 LEVER SWITCH LS001-C23OAB-LFA15B 01904090 LED COVER 01903512 7SEG LED LNM223KS01 01904167 LED SPACER FOR 7SEG LED LNM223KS01 01903901 DISPLAY COVER 01896145 LCD RCM6038T-1A ~01340290 TACT SWITCH EVQ11A H=5.0 00900189 D S-KEYTOP SX1H BLK ~00348490 LED (RED) SLR-325VCT31 00900156 D S-KEYTOP SD2H BLK 00900178 D S-KEYTOP SD4H BLK ~00125590 TACT SWITCH EVQ QJJ 05Q ~02011856 LED SLR-56DCT32 01013356 T S KEYTOP MD1H LCG 22495372 T S KEYTOP MD1H BLK 22495371 T S KEYTOP MX1H BLK 00899023 LED LNJ282RKRXE 01343090 LED SPACER 12499175 G S-BUTTON S1H BLK 249-175 01676512 PUSH SWITCH SDKLA1-B 13449720 DC JACK HEC2305-01-250 22360712 CORD HOOK 236-712 13429825 MIDI CONNECTOR YKF51-5054 2PZ 13449283 6.5MM JACK HLJ7101-01-3010 13449284 6.5MM JACK HLJ7001-01-3010 01235378 FOOT NO. PART CODE PART NAME DESCRIPTION
Page 2
JAN, 2000 MC-307 3 EXPLODED VIEW/ // /分解図 分解図分解図 分解図EXPLODED VIEW.eps EXPLODED VIEW PARTS LIST/分解図パーツリスト /分解図パーツリスト /分解図パーツリスト /分解図パーツリスト NO. PART CODE PART NAME DESCRIPTION Q'TY 01903889 TOP PANEL 71563989 TOP CASE ASSY 01904078 BOTTOM COVER 02015445 SHIELD SHEET 02015456 INSULATING SHEET 71454023 PANEL KEYTOP ASSY 71454045 SLIDER BOARD ASSY 71454012 MAIN BOARD ASSY (EXG) 01906801 STAY 01896145 LCD RCM6038T-1A(W/FLAT CABLE) 01120545 LEAF 02120190 BAN CARD BNCD-P=1.25-K-34-140 02014634 FUJI CARD 18X150-A6.0BBR-P1.25-HBL10 02128834 BAN CARD BNCD-P=1.00-K-16-300 40011101 SCREW M3X8 BINDING TAPTITE B FE BZC 3 40011123 SCREW M4X8 BINDING TAPTITE B BZC 7 40344145 SCREW M3X10 P TITE HEX SOCKET HEAD CAP BZC 4 40011267 SCREW M3X6 BINDING TAPTITE P FE ZC 32 40011278 SCREW M3X8 BINDING P-TITE FE ZC 7 40011312 SCREW M3X8 BINDING TAPTITE P FE BZC 2 40233012 SCREW M2.6X8 BINDING TAPTITE FEBZC 3 40011512 SCREW M3X12 SEMS. PAN HEAD FE BZC 1 40011501 SCREW M3X8 PAN MACHINE W/SW FE BZC 3 NO. PART CODE PART NAME DESCRIPTION Q'TY
Page 22
JAN, 2000 MC-307 23
