Revox G 36 Service Manual
This is the 52 pages manual for Revox G 36 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Revox G 36 Service Manual (Ocr-read)
Page 1
Contents 1 General 3 2 Mechanical Description 3 2.1 Mechanical checks and adjustments 4 2.1.1 Tape path 5 2.1.2 Brakes 5 2.1.3 Tape tension 7 2.1.4 Pinch roller 8 2.1.5 End of tape switch 8 2.1.6 Wow and flutter 9 2.1.7 Tape speed 10 2.2 Routine maintenance 10 2.2.1 Cleaning 10 2.2.2 Lubrication 10 2.2.3 Servicing of solenoids 11 2.2.4 Servicing of push button assembly 11 2.3 Removal of capstan assembly 11 3 Electronic Description 13 3.1 Circuit checks and adjustments 13 3.1.1 Measuring instruments 13 3.1.2 De-magnetising 14 3.1.3 Head alignment 14 3.1.4 Playback amplifier 16 3.1.5 Bias adjustment 17 3.1.6 Measurement of overall frequency response 18 3.1.7 VU-Meter adjustment 19 3.1.8 Adjustment of head shielding 20 3.1.9 Channel to channel crosstalk 20 3.2 Tuning the bias traps 21 4 Troubleshooting 22 4.1 Mechanical troubleshooting 22 4.2 Electronic troubleshooting 23 5 Technical Data 24 6 Circuit Diagram 26 7 SPARE PARTS LIST - ISSUE IV 39
Page 2
1 Genera l The REVOX Series 36 has been constantly improved and kept up to date, since it was first introduced in 1956. However, the pres ent G still bears the same basic layout and conception as did the original A recorder. Compared with the preceding models, th e following major innovations have been incorporated in the REVOX G 36 recorder : Hysteresis-Synchronous Capstan motor, VU-meters for record level control and a ta pe-tension switch to permit the use of all reels from 7 inch up to 10 1/2 inch diameter. The G 36 model is available in both 2 and 4 track versions. Identification is made by the appropriate number being stamped on th e head mounting plate, and on the upper side of the lower chassis. The recorder consists of an upper and lower chassis. These are joined at the rear by means of the back panel which carries the input and output sockets, mains voltage adjuster and fuse-holder, and at the front by means of the loudspeaker panel mountings. The upper chassis carries the tape transport mechanism and the lower chassis bears the power suppl y unit and the electronics. All Audio Connections are led to standa rd phono sockets. To interconnect the REVOX recorder with other Audio Equipmen t, a selection of adapter cables is available. 2 Mechanical Description The machine employs three motors. Two are identical and perform the wind and tension functions. The third motor is large and drives the capstan. It is of the pole switching variety and speed change is therefore effected electrically. The wind motors are designed to provide pulse free torque. Back tension is applied by electrical counter torque during the record and playback functions as well as during wind. The Capstan Motor is of the Hysteresis-S ynchronous type, incorporating a special design feature to prevent hunting. By switc hing to either the 6 or 12 pole stator winding, the tape speed of 7 1/2 or 3 3/4 ips may be selected. The capstan drive, the pinch roller assembly and the headblock with the tape guides are carried on one die- cast frame. This ensures accurately parall el and permanent alignment of all major transport elements. The coupling between motor and flywheel consists of special silicone-rubber strips, with th e whole assembly acting as a mechanical filter. A direct slip free drive is thus achieved whilst ma intaining negligible wow and flutter. The pinch roller is held against the capstan during record and replay functions with considerable pressure. This necessitate s the use of a capstan bearing designed specifically to withstand considerable side pressure for long periods. The pinch roller
