Revox B 710 Mk2 Owners Manual

Page 20

OVERVIEW OF MACHINE CONTROLS

INDEX LIST OF CONTROLS

CASSETTE DECK
[12][13][14][15] [16]

Ire] {911101

[[2] [3l [4] [5] [6] [[7]]

NPR?

[1] [11] [22]

TAPE DECK AND TIMER

[1] Mains switch

[2] Pause key

[3] Rewind key

[4] Fast-forward key

[5] Play key

[6] Stop key

[7] Record key

[8] Display mode selector

[9] Counter advance key (RUN UP)
[I 0] Counter and timer reset key
I

11] Display window

I
I
I
I
I
I

I
1
I
I
I
2

2] Memory SET key
3] Memory START key
4] Memory STOP key
5] Memory CLEAR/Headblock lift
6] Timer mode selector
2] Cassette compartment

REPRODUCE

[19] [20] [21] [25] [26]

REPRODUCE

[18] Tape bias selector

[19] Tape/Source monitoring switch

[20] Switch for DOLBY noise reduction
systems

[21] Selector for noise recuction system
DOLBY B or C

[25] Headphones jack

[26] Volume control for headphones jack

RECORD
[17] [28] [18]

[20] [21] [24] [23] [27]

RECORD

[17] MULTIPLEX filter switch

[18] Tape bias selector

[20] Switch for DOLBY noise reduction
systems

[2]] Selector for noise reduction system
DOLBY B or C

[23] Microphone jacks

[24] Microphone recording level controls

[27] Line recording level controls

[28] Peak reading meter
