Pyle plvsmn 6 owners manual
This is the 3 pages manual for pyle plvsmn 6 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pyle plvsmn 6 owners manual (Ocr-read)
Page 1
1. SPECIFICATION * OPTICAL - SCREEN SIZE ---------------- 6" DIAGONAL - DISPLAY FORMAT ---------- 1440(H) x 234(V) - COLOR CONFIGURATION -------- RGB Stripe - DOT PITCH ----------------- 0.107(H) x 0.372(V)* ELECTRICAL- COLOR SYSTEM ------------ NTSC/PAL auto switch- VIDEO INPUT ------------- 1 Vp-p, 75ohms- POWER SUPPLY ----------- DC12V - AUDIO OUTPUT POWER---------1W(MAX)- BRIGHTNESS---------------380 cd/m22. FUNCTION KEYS AT FRONT PANEL: - VIEWING ANGLE ------------------ Top:20 deg. / Bottom:50 deg. Left:45 deg. / Right:45 deg.MENU FUNCTION: POWER: Press the "Power" for ON/OFF MENU: Press or to adjust UP : To Adjust Volume Up DOWN : To Adjust Volume Down MUTE: Press "MUTE" to still the sound of the LCD monitor SPEAKERMENUMUTEPOWERUPDOWN
Page 2
3. FUNCTION5. SUN VISOR KIT4. DIMENSION 23.6 112.3 146.9 196 26 130 DC +12V (RED)GND (BLACK) VIDEO INPUT (YELLOW) AUDIO INPUT L (WHITE) AUDIO INPUT R (RED) CAR CABLE DIN CABLE
