Prology hdtv 2600 service manual
This is the 66 pages manual for prology hdtv 2600 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from prology hdtv 2600 service manual (Ocr-read)
Page 1
SERVICE MANUAL CONTENTS Contents ------------------------------------------------------------------------- 2 Safety precautions ----------------------------------------------------------- 3 Servicing precautions ------------------------------------------------------- 4 Specifications ------------------------------------------------------------------ 5 Location of control ----------------------------------------------------------- 9 Trouble Shooting ------------------------------------------------------------- 12 Deassembly procedure ---------------------------------------------------- 14 Exploded Drawing ----------------------------------------------------------- 19 Wire dressing ------------------------------------------------------------------ 21 Adjustment instruction with Default Factory Data----------------- 22 Inspection instruction ------------------------------------------------------ 24 PCB Layout --------------------------------------------------------------------- 28 Schematic Diagram -----------------------------------------------------------33 Replacement part list -------------------------------------------------------- 34 Block Diagram ----------------------------------------------------------------- 41 Circuit descriptions ---------------------------------------------------------- 42
Page 2
SERVICE MANUAL SAFETY PRECAUTIONS Leakage Current Hot Check (See below Figure) Plug the AC cord directly into the AC outlet. Do not use a line Isolation Transformer during this check. Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor between a known good earth ground (Water Pipe, Conduit, etc.) and the exposed metallic parts. Measure the AC voltage across the resistor using AC voltmeter with 1000 ohms/volt or more sensitivity. Reverse plug of the AC cord into the AC outlet and repeat AC voltage measurements for each exposed metallic part. Any voltage measured must not exceed 0.75 volt RMS, which is, corresponds to 0.5mA. In case any measurement is out of the limits specified, there is possibility of shock hazard and the set must be checked and repaired before it is returned to the customer. Leakage Current Hot Check circuit !! Important Safety Notice !! Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer.
