XV-DV55 2 EXTERIOR PACKING 1. CONTRAST OF MISCELLANEOUS PARTS CONTRAST TABLE XV-DV55/ALBXJ and XV-DV55/APWXJ are constructed the same except for the following : PACKING P5 - 4 AC Power Cord ADG1160 ADG1154 P5 - 4 AC Power Cord Not used ADG1158 P5 - 6 Operating Instructions (Basic) (English/ French) ARE7262 Not used P5 - 6 Operating Instructions (Basic) (English/ Chinese) Not used ARE7275 P5 - 8 Operating Instructions (English) ARB7228 Not used P5 - 8 Operating Instructions (English/ Chinese) Not used ARE7274 P5 - 15 NSP Warranty Card ARY7047 Not used P5 - 23 Packing Case AHD7914 AHD7956 EXTERIOR P7 - 19 Rear Panel (Mtl) ANC7957 ANC7987 P7 - 42 Name Lable ARW7098 ARW7115 NSP Label Not used VRW1629 No.1 Distination Label Not used AAX7859 No.2 Part No. XV-DV55/ APWXJ Ref. No. Symbol and Description Remarks MarkXV-DV55/ ALBXJ EXPLODED VIEWS - The numbers in the remarks column correspond to the numbers on the exploded diagram, Refer to "EXPLODED VIEWS". Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screws adjacent to mark on product are used for disassembly. Reference Nos. indicate the pages and Nos. in the service manual for the base model. NOTES: When ordering resistors, first convert resistance values into code form as shown in the following examples. Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%, and K=10%). Ex.2 When there are 3 effective digits (such as in high precision metal film resistors). 561 473 R50 1R0 5621 560 47k 0.5 1RD1/4PU J RD1/4PU J RN2H K RS1P K 56 x 10 1 47 x 10 3 R50 1R0561 473 5.62k RN1/4PC F562 x 10 1 5621 Name Label No.1 No.2 (2/2) No.2 (1/2) Packing Case
