Pioneer xrvs 100 d service manual
This is the 6 pages manual for pioneer xrvs 100 d service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer xrvs 100 d service manual (Ocr-read)
Page 1
XR-VS100D 2 Part No. Ref. No. Mark Symbol and Description XR-A9700DV XR-VS100D Remarks /KUCXJ /YPWXJ PCB ASSEMBLIES COMPLEX ASSY AWM7485 AWM7484 P7- 4 POWER ASSY AWU7538 AWU7510 P7- 5 PRIMARY ASSY AWU7516 AWU7513 P9- 1 DISPLAY ASSY AWU7515 AWU7530 PACKING SECTION P5- 1 Power Cord ADG7022 ADG1160 P5-10 Packing Case AHD7794 AHD7809 P5-11 NSP Warranty Card ARY7033 ARY7027 NSP Polyethylene Bag Not used AHG7033 For Power Cord EXTERIOR SECTION P7-13 Power Transformer (AC120V) ATS7267 Not used P7-13Power Transformer Not used ATS7266 (AC110-127V/220-230V/240V) P7-14 Fuse (FU1 : 8A) REK1086 Not used P7-14Fuse (FU1 : T6.3A) Not used REK1030 P7-25 Rear Panel ANC7867 ANC7873 P7-41 NSP Fuse Card AAX2332 Not used P7-42 NSP Getter AAX7745 AAX7748 P7-43 65 Label ARW7050 Not used FRONT PANEL SECTION P9-23 Display Panel AAK7722 AAK7724 P9-28 Front Panel AMB7650 AMB7651 XR-VS100D/YPWXJ and XR-A9700DV/KUCXJ are constructed the same except for the following : Notes : For PCB ASSEMBLIES, Refer to ÒCONTRAST OF PCB ASSEMBLIESÓ and Ò2. SCHEMATIC DIAGRAMÓ. 1. CONTRAST OF MISCELLANEOUS PARTS Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screws adjacent to mark on product are used for disassembly. Reference Nos. indicate the pages and Nos. in the service manual for the base model. NOTES: When ordering resistors, first convert resistance values into code form as shown in the following examples. Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%, and K=10%). Ex.2 When there are 3 effective digits (such as in high precision metal film resistors). 561 473 R50 1R0 5621 560 47k 0.5 1RD1/4PU J RD1/4PU J RN2H K RS1P K 56 x 10 1 47 x 10 3 R50 1R0561 473 5.62k RN1/4PC F562 x 10 1 5621 CONTRAST TABLE
Page 2
XR-VS100D 3 CONTRAST OF PCB ASSEMBLIES POWER ASSY F N PRIMARY ASSY F M AWU7513 and AWU7516 are constructed the same except for the following : DISPLAY ASSY Mark Symbol and DescriptionPart No. Remarks AWU7516 AWU7513 R1 (2.2MW/ 1/2W) RCN1080 Not usedAN1 1P AC INLET XKP3042 XKP3041CN2 KE CONNECTOR 4P Not used B4P7-VHKN2 EARTH METAL FITTING VNF1084 Not used AWU7530 and AWU7515 are constructed the same except for the following : Mark Symbol and DescriptionPart No. Remarks AWU7515 AWU7530 R5583 Not used RS1/10S223JR5584 RS1/10S223J Not used AWU7510 and AWU7538 are constructed the same except for the following : Mark Symbol and DescriptionPart No. Remarks AWU7538 AWU7510 NSP Y3301 JUMPER WIRE ADX7324 Not used NSP Y3302 JUMPER WIRE ADX7325 Not used PCB BINDER VEF1040 Not used F L
