Page 1
VSX-D608, VSX-D608-G 2Part No. Ref. No. Mark Symbol and Description VSX-D608 VSX-D608 VSX-D608-GRemarks /KUXJI /SDXJI /SDXJI PCB ASSEMBLIES NSP INPUT ASSY AWK7472 AWK7473 AWK7473 P5 - 2 FRONT ASSY AWX7215 AWX7216 AWX7216 NSP AMP ASSY AWK7480 AWK7481 AWK7481 P5 - 5 AMP ASSY AWX7223 AWX7224 AWX7224 P5 - 7 TRANS1 ASSY AWX7231 Not used Not used NSP EXCELLENT ASSY AWK7485 AWK7518 AWK7518 P5 - 16 FRONT LARGE ASSY AWX7288 AWX7379 AWX7379 PACKING P3 - 7 NSP Warranty Card ARY7023 Not used Not used P3 - 13 Packing Case AHD7692 AHD7693 AHD7694 Operating Instructions Not used ARC7243 ARC7243 No.1 (Spanish/Chinese)Caution 220V Label Not used ARR1003 ARR1003 No.2 EXTERIOR SECTION P5 - 18 Power Transfomer (T1) ATS7234 ATS7236 ATS7236 P5 - 19Fuse (FU1 : 10A) REK1087 REK1132 REK1132 P5 - 20Fuse (FU2 : 7A) VEK1027 Not used Not used P5 - 20Fuse (FU2 : 4A) Not used REK1133 REK1133 P5 - 26AC Power Cord ADG7024 VDG1058 VDG1058 P5 - 28 Cord Stopper CM-22C CM-22B CM-22B P5 - 29 Tuner Holder AAD7490 AAD7490 AAD7492 P5 - 31 Rear Panel ANC7724 ANC7721 ANC7764 P5 - 32 Bonnet Case AZN7762 AZN7762 AZN7756 P5 - 41 Volume Knob AAB7179 AAB7179 AAB7180 P5 - 43 Function Button AAD7500 AAD7500 AAD7487 P5 - 44 Power Button AAD7440 AAD7440 AAD7485 P5 - 46 Display Window AAK7606 AAK7606 AAK7648 P5 - 47 Front Panel AMB7552 AMB7552 AMB7578 P5 - 49 Name Plate PAM1776 PAM1776 PAM1779 P5 - 57 Screw (´3, For Front Panel) BBZ30P080FZK BBZ30P080FZK BBZ30P080FCC P5 - 57 Screw (´5, For Bonnet Case) BBZ30P080FZK BBZ30P080FZK BBZ30P080FCC P5 - 60 Screw (´2, For Bonnet Case) FBT40P080FZK FBT40P080FZK FBT40P080FNI P5 - 67 FM/AM TUNER Unit AXX7046 AXX7047 AXX7047 Fuse (FU3 : 4A) Not used REK1133 REK1133 No.3 Voltage Selector Not used AKX-507 AKX-507 No.4Voltage Selector Not used AKX1004 AKX1004 No.5 1. CONTRAST OF MISCELLANEOUS PARTS 7 CONTRAST TABLE VSX-D608/SDXJI, VSX-D608-G/SDXJI and VSX-D608/KUXJI are constructed the same except for the following: NOTES :ÖParts marked by Ò NSP Ó are generally unavailable because they are not in our Master Spare Parts List. ÖThe mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. ÖReference Nos. indicate the pages and Nos. in the service manual for the base model. ÖWhen ordering resistors, first convert resistance values into code form as shown in the following examples. Ex. 1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J = 5%, and K = 10%). 560 W = 56 ´ 10 1 = 561 ...................................................RD1/4PU 5 6 1 J 47k W = 47 ´ 10 3 = 473 ..................................................RD1/4PU 4 7 3 J 0.5 W = R50 ......................................................................RN2H å 5 0 K 1 W = 1R0 .........................................................................RS1P 1 å 0 K Ex. 2 When there are 3 effective digits (such as in high precision metal film resistors). 5.62k W = 562 ´ 10 1 = 5621...........................................RN1/4PC 5 6 2 1 F ¦ The numbers in the remarks column correspond to the numbers on the Ò EXPLODED VIEWS Ó. ¦ For PCB ASSEMBLIES, Refer to Ò CONTRAST OF PCB ASSEMBLIES Ó and Ò 2. SCHEMATIC DIAGRAM Ó.
Page 2
VSX-D608, VSX-D608-G 3 7 EXPLODED VIEWS ¦ PACKING ¦ EXTERIOR SECTION Polyethyene Bag Rear Pad (2/2) Rear Pad (1/2) Front Pad (1/2) Sub Instruction Manual Operating Instructions (English) No.1 Alkaline Dry Cell Battery (LR6, AA) Packing Sheet Front Pad (2/2) No.2 AC Power Cord Cord Stopper Rear Panel No.5No.4 (FU1) (FU2)No.3 (FU3) AMP Assy Screw BBZ30P080FZK
