Pioneer sound. vision. soul

Service 1.7;
Manual

AUDIONIDEO MULTI-CHANNEL RECEIVER

VSX-AX5i-S
VSX-AX3-S
VSX-AX3-K

THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).

ORDER NO.

RRV2801

VSXrAXSirS

Model Type Power Requirement The voltagjlim:;:1:rt1¥:rdted by the
VSX-AXSi-S HYXJI A0220-23OV A0240V, *
VSX-AXS-S HYXJI A0220-23OV AC24OV, *
VSX-AXS-K HYXJI A0220-230V AC24OV, *

*:Alter the wiring of the power-supply block at the primary winding of Power transformer referring to the Line Voltage Selection
described in Service Manual.

09

For details, refer to "Important symbols for good services".

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. BOX 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium

PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936

©PIONEER CORPORATION 2003 T-ZZE JULY 2003 printed in Japan
