Pioneer sound. vision. sou/
Service
Manual $6593
AUDIONIDEO MULTI- CHANNEL RECEIVER
VSX-91 8V-
vsx- 918V-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement The VOItagfllgmrg ;:?:::?d by the
VSX-918V-K SDXJ AC 110 V/120 V to 127 V/220 V/230 V to 240 V With the voltage selector
VSX-918V-K YPWXJ AC 240 V ______
VSX-918V-S YPWXJ AC 240 V ______
VSX-918V-S SFLXJ AC 110 V/120 V to 127 V/220 V/230 V to 240 V With the voltage selector
VSX-918V-S NAXJ5 AC 220 V ______
This service manual should be used together with the following manual(s):
Model Order No. Remarks
VSX-918V-K/MYSXJ5 RRV3736
For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.
CONTENTS
1. CONTRAST OF MISCELLANEOUS PARTS ......................................................................................................................... 2
2. SCHEMATIC DIAGRAM
2.1 PRIMARY ASSY ........
PIONEER CORPORATION 4-1, Meguro1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. PO. BOX 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
CPIONEER CORPORATION 2008
T-ZZK MAY 2008 Printed in Japan
