Extracted text from pioneer vsx 11 service manual (Ocr-read)
Page 1
VSX-11 2 1. CONTRAST OF MISCELLANEOUS PARTS CONTRAST TABLE VSX-11/KUXJI/CA and VSX-D507S/KUXJI are constructed the same except for the following : Remarks Ref. No. KUXJI/CA Symbol and Description MarkVSX-11 Part No. VSX-D507S KUXJI NOTES :ÖParts marked by Ò NSP Ó are generally unavailable because they are not in our Master Spare Parts List. ÖThe mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing,be sure to use parts of identical designation. ÖReference Nos. indicate the pages and Nos. in the service manual for the base model. ÖScrew adjacent to ° mark on the product are used for disassembly. ÖWhen ordering resistors, first convert resistance values into code form as shown in the following examples. Ex. 1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J = 5%, and K = 10%). 560 W = 56 ´ 10 1 = 561 ...................................................RD1/4PU 5 6 1 J 47k W = 47 ´ 10 3 = 473 ..................................................RD1/4PU 4 7 3 J 0.5 W = R50 ......................................................................RN2H å 5 0 K 1 W = 1R0 .........................................................................RS1P 1 å 0 K Ex. 2 When there are 3 effective digits (such as in high precision metal film resistors). 5.62k W = 562 ´ 10 1 = 5621...........................................RN1/4PC 5 6 2 1 F ASSEMBLIES NSP MOTHER Assy AWK7432 AWK7437 P5-1 INPUT Assy AWX7102 AWX7106 P5-2 R/C SP&6CH Assy AWX7092 Not used P5-3 REG Assy AWX7093 AWX7203 HP&FAV Assy AWX7103 Not used NSP FRONT & PS Assy AWK7433 AWK7438 P5-6 POWER SUPPLY Assy AWX7096 AWX7204 P5-7 VIDEO Assy AWX7105 AWX7110 P6-2 FL&UCOM Assy AWX7104 AWX7107 P6-4 VOLUME Assy AWX7097 AWX7205 NSP ELITE ASSY Not used AWK7439 LARGE FSP Assy Not used AWX7108 No.1 LAGE RCSP Assy Not used AWX7109 No.2 HP ASSY Not used AWX7159 No.3 PACKING P3-3 Operating Instructions (English) ARB7134 ARB7135 P3-4 NSP Warranty Card ARY1051 ARY7007 P3-11 Packing Case AHD7554 AHD7556 EXTERIOR SECTION P5-11 Power Transformer T1 (AC120V) ATS7207 ATS7208 P5-17 Flat Flexible Cable (12P) ADD7090 ADD7091 P5-19 Rear Panel ANC7624 ANC7626 P5-26 Foot Assy (Rear Side) REC1263 Not used P5-30 Screw ABA7043 ABA1022 Screw Not used ABA1193 No.4 Screw Not used ABA7023 No.5 Screw Not used ABA7035 No.6 FCC Label Not used VRW1725 No.7 DOC Label Not used VRW1726 No.8 Fuse (FU4: 10A) Not used REK1087 No.9 FRONT PANEL SECTION P6-16 Sub Panel AAP7041 AAP7039 P6-17 Front Panel AMB7486 AMB7487 P6-24 Housing 5P Shield ADX7238 Not used Plate Spring Not used ABK7011 No.10 Door Hinge L Not used AMR7171 No.11 Door Hinge R Not used AMR7172 No.12 Door Panel Not used AAK7561 No.13 PVC Panel Not used AAK7534 No.14 Dumper Assy Not used AXA7046 No.15 Door Plate Not used ANG7187 No.16 Collar Spacer Not used AEC7146 No.17 Note: The numbers in the remarks column correspond to the numbers on the exploded diagram, Refer to ÒEXPLODED VIEWSÓ. For ASSEMBLIES, Refer to Ò CONTRAST OF PCB ASSEMBLESÓ and Ò2. SCHEMATIC AND PCB DIAGRAMSÓ.
Page 2
VSX-11 3 No.4 No.4 BBT30P080FCC BBT30P080FCC BBT30P080FCC BBT30P080FCC Rear panel No.10 No.2No.7 No.8 No.1 BPZ30P080FMC Front Panel BPZ30P080FMC No.15 Sub Panel BPZ30P080FZK BPZ30P080FZK No.12 No.5 No.13 No.5No.11No.16 No.14 No.5 (D-faced tape) (D-faced tape) No.6 BPZ30P080FMC BPZ30P080FMC ABA7009 No.17 No.3 Power SW Assy ABA7046Screw ABA7046ScrewScrew Screw Screw Screw Screw Screw Screw Screw Screw Screw Screw Front Bonnet Case No.9 Power Supply AssyFuse FU2: 6.3A Fuse FU1: 10A FRONT PANEL SECTION EXTERIOR SECTION EXPLODED VIEWS
