Pioneer tre 1066 service manual
This is the 8 pages manual for pioneer tre 1066 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer tre 1066 service manual (Ocr-read)
Page 1
GD PIONEER
The Art ofEntertainment
RENAULT
Service
anual
TRANSMITTER INTERFACE
THE-Imznw w.
THE-IOSBZRN mam
ORDER NO.
CRT1898
VEHICLE DESTINATION PRODUCED AFTER RENAULT PART No. ID No. PIONEER MODEL No.
MATRA ESPACE EUROPE JULY 1996 6025 30 1242 H TRE-1066ZRN/WL
TRE-10662RN/X1B/WL
CONTENTS
1. SPECIFICATIONS ........................................................ 2 6. BLOCK DIAGRAM ...................................................... 5
2. CONNECTOR FUNCTION DESCRIPTION ................. 2 7. CIRCUIT DIAGRAM AND PATTERN .......................... 6
3. CAR AUDIO SYSTEM ................................................. 3 8. EXPLODED VIEW AND PARTS LIST ......................... 8
4. ADJUSTMENT ............................................................ 4 9. PACKING METHOD .................................................... 8
5. ELECTRICAL PARTS LIST .......................................... 5
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153, Japan
PIONEER ELECTRONICS SERVICE INC. P.0.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 501 Orchard Road, #10-00, Lane Crawford Place, Singapore 0923
© PIONEER ELECTRONIC CORPORATION 1996 K_FFM_ JULY 1996 Printed in Japan
