Pioneer sx 303 r owners manual

Page 1

STEREO RECEIVER

SX~303R
SX-ZSER
SX-ZO3

Thank you for buying this Pioneer product.

Please read through these operating instructions so you will
know how to operate your model properly. After you have
finished reading the instructions, put them away in a safe place
Ior future reference.

In some countries or regions, the shape of the power plug and
power outlet may sometimes differ from that shown in the
explanatory drawings. However, the method of connecting
and Operating the unit is the same.

Operating

Instructions

4

WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO RAIN 0R MOISTURE.

IMPORTANT NOTICE

[For U.$. and Canadian models]

The serial number for this equipment is located on the rear panel.
Please write this serial number on your enclosed warranty card
and keep it in a secure area. This is for your security

[For Canadian models)

CAUTION:

TO PREVENT ELECTRIC SHOCK DO NOT USE THIS
IPOLARIZEDIPLUG WITH AN EXTENSION CORD, RECEP~
TACLE OR OTHER OUTLET UNLESS THE BLADES CAN
BE FULLY INSERTED TO PREVENT BLADE EXPOSURE

ATTENTION:

POUR PREVENIR LES CHOCS ELECTHIQUES NE PAS
UTILISER CETTE FICHE POLARISEE AVEC UN PROLON-
GATEUR UNE PRISE DE COURANT 0U UNE AUTRE SOR-
TIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE
INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE
A DECOUVERT.

TWO VOLTAGE SELECTOR SWITCHES

Only multi-voltage models are provided with these

switches. U.S. Canadian models are not provided with

these switches.

Main voltages in Saudi Arabia are 127 V and 220 V only, Never

use this model with 110 V setting in Saudi Arabia.

The line voltage selector switches are on the rear panel. Before

your model is shipped from the Iactory, these switches are set to

the power requirements of the destination. Check that they are

set properly before plugging the power cord into the AC outlet. II

the voltage is not properly set or if you move to an area where the

voltage requirements dilfer, adjust the selector switches as

follows.

1. Disconnect the power cord.

2. Use a medium-size screwdriver.

3 Insert the screwdriver into the groove on the voltage selec-
tors and adjust so that the tip of the allow points to the vol»
tage value of your area. '

I. no .m
Set the voltage selector switch to the voltage in your area
lonly SX-303R).

may now
Izora'rv! 1' now

Information to User

Alteration or modifications carried out without appropriate authorization may invalidate the user's right to oprerate the equipment.
