Pioneer semj 5 service manual
This is the 4 pages manual for pioneer semj 5 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer semj 5 service manual (Ocr-read)
Page 1
2 1234 1234 C D F A B E SE-MJ5 SPECIFICATIONS ModelFrequency responceImpedancMaximum Input powerSensitivity Driver unitPlug CordWeight (Without cord) SE-MJ5 5 Hz to 28 000 Hz 32 Ω1 500 mW (JEITA) 105 dBΦ 40 mm S/S/W S/L S S1.5 m + 2.0 m 220 g SE-MJ3 10 Hz to 25 000 Hz 32 Ω1 000 mW (JEITA) 105 dBΦ 40 mm Φ 40 mm0.5 m + 1.0 m 100 g SE-MJ2 12 Hz to 22 000 Hz 32 Ω500 mW (JEITA) 103 dB 1.2 m100 g SE-CL25DN 8 Hz to 22 000 Hz 16 Ω100 mW (JEITA) Plug form : S (straight type) / L (L type) / W (2Way plug) 100 dBΦ 9.2 mm 0.55 m 4 g
Page 2
3 1234 123 4 C D F A B E SE-MJ5 Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST For Parts List Mark No. Description Part No. For Parts List Mark No. Description Part No. NSP 1 Head phone WPH1031 NSP 2 Cord Assy WDE1277 3Pulg Adapter WKX1036 4Extension Cord WDE1274 5Ear Pad Assy WXA1054 6Ear Pad Assy WXA1055 NSP 1 Head phone WPH1032 NSP 2 Cord Assy WDE1278 3Ear Pad WNV1130 4Extension Cord WDE1181 EXPLODED VIEW PACKING VIEW 36 5 4 1 1 2 EXPLODED VIEW PACKING VIEW 4 21 13 3 - SE-MJ3 - SE-MJ5
