Pioneer sw 37 service manual

This is the 2 pages manual for pioneer sw 37 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 2
pioneer sw 37 service manual

Extracted text from pioneer sw 37 service manual (Ocr-read)


Page 1

2Mark No. Description Part No. SCHEMATIC DIAGRAM For Packing Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. S-W37 Network ASSY FRWN-100 NSP Badge FRAM-026 NSP Label Back FRAN-223 Input Terminal FRKX-008 Port Ring FRNK-141 Speaker (Woofer) P12EC65-57D Screw (for Woofer) FRBA-011 Screw (for Back Board) FRBA-016Speaker Wire (2m) FRDD-042 NSP Warranty Card FRRY-022 Protector FRHA-086 Protection Mat S4 FRHC-020 Packing Case FRHG-213 Network ASSY (FRWN-100) Woofer 2 INPUT 2.7mH Woofer 1 INPUT 2.7mH Operating Instructions FRRD-129 (English /French/German /Dutch /Italian /Swedish /Spanish /Portuguese)
