Extracted text from pioneer sta 505 service manual (Ocr-read)
Page 1
2 1 23 4 1234 C D F A B E S-TA505 6-(2/2) 75-(2/2) 5-(1/2) 5-(1/2)1 1 7 5-(2/2) 10 4 892 3 6-(1/2) 4Speaker Stand Base SMS6027 5Protector SHA6110 6Protector (Middle) SHA6111 7Protection Sheet SHC6051 8Protection Sheet SHC6052 9Polyethylene Bag S2 SHL1417 10 Packing Case SHG6219 NSP Model Label (FL) SAN6365 NSP Model Label (FR) SAN6366 NSP Model Label (SL) SAN6367 NSP Model Label (SR) SAN6368 NSP Model Label (C) SAN6369 Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: NSP 1 Front, Surround Speaker SMW6198 NSP 2 Center Speaker SMW1931 NSP 3 Accessory Set SME6089 Speaker Wire (FL: White) SDS1174 Speaker Wire (FR: Red) SDS1175 Speaker Wire (SL: Blue) SDS1176 Speaker Wire (SR: Gray) SDS1177 Speaker Wire (C: Green) SDS1178 NSP Screw Set SME6071 Screw CYC40P250FTC Polyethylene Bag S0 SHL1314 Large Non Skid Pad SEP6014 (for Front, Surround Speaker) Small Non Skid Pad SEP6017 (for Center Speaker) Large Non Skid Pad SEC2070 (for Subwoofer) Polyethylene Bag S2 SHL1251 PACKING Parts List Mark No. Description Part No. Mark No. Description Part No. 2.1 PACKING 2. EXPLODED VIEWS AND PARTS LIST
Page 2
3 1 234 1 23 4 C D F A B E S-TA505 5 10 11 (x3) 12 (x8) 2 76 9 1 8 (x2) 3 4 Model Label Speaker Stand Base ( refer to 2.1 PACKING / No.4 ) Screw ( refer to 2.1 PACKING / No.3 Accessory Set )12 (x2) : the bosses of the grille FRONT, SURROUND SPEAKER Parts List NSP 1 Cabinet SMM6043 2Grille SMG6109 NSP Grille Cloth SAS6068 NSP Grille Frame SMH6017 3Cosmetic Plate Assy SXB6004 NSP Badge SAM1507 NSP Cosmetic Plate SNK6131 4Input Terminal SKX1060 5Fastener SNB1073 6Network Assy SWN6020 NSP 7 Acoustic Absorbent SMT6015 8Packing SEC6083 9Speaker (Woofer) K77DC55-51F 10 Speaker (Tweeter) FK26AP32-51F 11 Screw BYC35P160FTB 12 Screw BYC35P120FTB 2.2 FRONT, SURROUND SPEAKER Mark No. Description Part No.
