Extracted text from pioneer smr 7 service manual (Ocr-read)
Page 1
2 S-MR7 Mark No. Description Part No. Network ASSY (SWN1620) SCHEMATIC DIAGRAM For Packing Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. NSP Cabinet (for UC Type) SMM1873 NSP Cabinet (for EW Type) SMM1878 Grille SMG1671 NSP Grille Cloth SAS1467 NSP Cushion SEC1441 NSP Grille Frame SMH1007 Catch SNK2449 Network Assy SWN1620 Input Terminal KKX1014 NSP Badge SAM1471 Non Skid Pad SEC1374 NSP Stamped Model Label (for UC Type)SME2996 NSP Model Label SAN2781 NSP Stamped Model Label (for EW Type)SME2995 NSP Model Label SAN2780 NSP Paper Tube 45 SMR1311 NSP Acoustic Absorbent SMV1955 Speaker(WF) B13ER71-51D Speaker(TW) FK26AP02-54D Screw(for TW) SBA1178 Screw(for WF) SBA1179 Catch SLH1065Speaker Wire SDS1078 Protector(T) SHA2200 Protector(B) SHA2201 Packing Case (for UC Type) SHG2245 Packing Case (for EW Type) SHG2244 NSP Polyethylene Bag SHL1212 Woofer 1.5µF Tweeter I N White RED White Blue White Blue
Page 2
3 S-MR7 PRODUCT APPEARANCE 182 320 12 11 6 5 4 3 2 1 (232.5) 210 to Input Terminal to WFto TW 13 15 14 10 9 8 7 No. 1 2 3 4 5 6 7 8 9 10 Part name Cabinet Speaker (Tweeter) Catch Speaker (Woofer) Grille Badge Duct Stamped Model Label Input Terminal Acoustic Absorbent Num. 1 1 4 1 1 1 1 1 1 1 Remarks No. 11 12 13 14 15 16 17 18 19 20 Part name Screw (M3) Screw (M4) Staple Network Assy Non Skid Pad Num. 4 4 2 1 4 Remarks
