Extracted text from pioneer sis 21 v service manual (Ocr-read)
Page 1
2 S-IS21V Mark No. Description Part No. Network ASSY (SWN1604) SCHEMATIC DIAGRAM For Packing Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. NSP Cabinet SMM1853 NSP Inner Baffle SNK2398 Network ASSY SWN1604 Input Terminal KKX1014 Non-Skid Pads SEC1374 NSP Packing SEC1444 NSP Stamped Model Label (for XJI/E type)SME3074 NSP Model Label SAN2861 NSP Stamped Model Label (for XJI/NC type)SME3075 NSP Model Label SAN2862 NSP Acoustic Absorbent SMV1886 NSP Punching Net SNC1174 Cosmetic Baffle ASSY SXB1372 Packing SEC1445 NSP Cosmetic Baffle SNK2399 NSP Cosmetic Ring SNK2400 Speaker (Woofer) A16LC83-53D Speaker (Mid-range) FD66AP45-55D Screw (for Woofer) BPZ40P120FMCSpeaker Cord (for XJI/E type) SDS1064 Speaker Cord (for XJI/NC type) SDS1057 Top Protector SHA2170 Bottom Protector SHA2171 NSP Polyethylene Bag SHL1212 Packing Case (for XJI/E type) SHG2293 Packing Case (for XJI/NC type) SHG2294 Woofer Mid-range I NPUT Tweeter 1.5µF/63V Blue White Red BlackRed White White Blue
Page 2
3 S-IS21V PRODUCT APPEARANCE 8 912 10 1Screw BPZ40P120FMC6 11 Acoustic Absorbent 72 4 1 Non Skid Pad Model Label Cosmetic Baffle Assy Input Terminal Punching NetStaple Cabinet Speaker Speaker 4 1 1 1 1 1 6 5 4 3 2 1Part name Num. No. Remarks Part name Num. No. Remarks 1 Network Assy KKX1014 Woofer Mid-range 210 0.5 (366.5) 194 1 (267.6) BLUE WHITE REDWHITE BLACK RED + – + – 8 2 1 4 5 6 9 9 3 7 10 11 11 12
