Pioneer shf 5 service manual
This is the 2 pages manual for pioneer shf 5 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer shf 5 service manual (Ocr-read)
Page 1
2 Network ASSY (SWN1575) SCHEMATIC DIAGRAM For Packing Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. Mark No. Description Part No. NSP Accessories ASSY SME2762 Speaker Cord SDS-002 NSP Polyethylene Bag SHL-185 Operating Instructions SRD1195 Protector-A (Top) SHA2051 Protector-B (Bottom) SHA2052 Protection Mat S5 SHC1519 Packing Case SHG2093 S-HF5 Woofer 1.0µF Tweeter INPUT Red White Red Black Blue White 0.3mH NSP Cabinet SMM1802 Grille ASSY SMG1560 Badge SAM1396 Badge SAM1393 NSP Badge Base SNK1987 NSP Grille Net SAS1408 NSP Grille Frame SNK2134 Network ASSY SWN1575 Cosmetic Packing SEB1210 NSP Input Terminal SKX1050 NSP Label SME2763 NSP Label SAN2561 NSP Duct 70 SMR1278 NSP Absorbent (for Baffle) SMV1871 NSP Absorbent (for Cabinet) SMV1902 Fastener SNB1043 NSP Catch SNK-883 NSP Cosmetic Duct SNK2301 Speaker (Woofer) SWM1056 Speaker (Mid-range) FP66AP45-58L Screw (for Fastener) RWC31P160FZB Fixing Bolt (for Tweeter) SBA1095 Fixing Bolt (for Woofer) SBA1148
