Pioneer shf 11 c service manual

This is the 3 pages manual for pioneer shf 11 c service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 3
pioneer shf 11 c service manual

Extracted text from pioneer shf 11 c service manual (Ocr-read)


Page 1

2 1 23 4 1234 C D F A B E S-HF11C Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. SCHEMATIC DIAGRAM 1Protector SHA2528 2Protection Sheet SHC1839 3Packing Case SHG2691 4Operating Instructions SRD1305 (English, French) 2 Speaker System 4 2 1 1 3 Mark No. Description Part No. Network Assy SWN1767 Grille SMG1857 Input Terminal SKX1100 Speaker (Tweeter) SWD9007 Speaker (Woofer) SWM9021 Screw (for Tweeter) BYC30P180FZB Screw (for Woofer) BKC35P180FZB For Packing Speaker System Network Assy (SWN1767) C I N Black Blue BlackRed BlackRed 1.8 µF/50V Woofer T135/60P.SW Tweeter Woofer P.SW P.SW has extreme positive resistance-temperature characteristics. (Less than 0.3W at the normal temperature). If an abnormal current flows to P.SW due to an excessive input or unusual signal, P.SW heats up and the resistance rapidly increases. With this function, the speakers are protected from excessive input or unusual signal. The resistance value increases even when using a soldering iron for repairing, so allow it to cool before using.

Page 2

3 1 234 1 23 4 C D F A B E S-HF11C 1 1 2 Input Terminal1 1 121 Screw 118 3 1 10 1 1 4 Part Name No. Num. 9 8 7 6 5 4 3 2 1 Catch Screw Grille Cabinet Model Label Duct Network Assy Acoustic Absorbent Woofer Tweeter PRODUCT APPEARANCE
