Pioneer sh 509 v service manual

This is the 2 pages manual for pioneer sh 509 v service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 2
pioneer sh 509 v service manual

Extracted text from pioneer sh 509 v service manual (Ocr-read)


Page 1

S-H509V 2 NOTES : Parts marked by Ò NSP Ó are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Mark No. Description Part No. PARTS LIST Mark No. Description Part No. Grille Assy FRMG-180 Network Assy FRWN-163 Duct FRNK-386 Speaker (Woofer) B13DC70-51M Speaker (Tweeter) K26EP09-51D Screw (for Woofer) FRBA-028 Screw (for Tweeter) FRBA-027 Catch FRNK-015 Woofer Ring FRNK-382 Tweeter Ring FRNK-383 Base FRXK-003Operating Instructions FRRD-139 Protector FRHA-186 Protector FRHA-190 Packing Case FRHG-280 Accessory FREA-012 SCHEMATIC DIAGRAM Woofer 2.2 mF/63V Tweeter Black Red Blue White White Red NETWORK ASSY (FRWN-163) Black Red Woofer Blue White Woofer Blue White 0.82 mH 0.33 mH I NPUT TERMINAL I NPUT TERMINAL For Packing
