Extracted text from pioneer sfcrw 2500 service manual (Ocr-read)
Page 1
2 1 23 4 1234 C D F A B E S-FCRW2500 For Packing Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. Mark No. Description Part No. CS ASSY (Surround) NSP Cabinet SNK2840 Grille SMG1835 NSP Badge 28 SAM1506 NSP Grille Cloth SAS1588 NSP Baffle SNK2843 Speaker Wire SDD1342 Speaker Wire SDD1343 Speaker K77DU55-52D Screw BPZ35P120FNI CS ASSY (Front) Mark No. Description Part No. NSP Cabinet SNK2840 Grille SMG1835 NSP Badge 28 SAM1506 NSP Grille Cloth SAS1588 NSP Baffle SNK2843 Speaker Wire SDD1340 Speaker Wire SDD1341 Speaker K77DU55-54D Screw BPZ35P120FNI NSP CS Assy (Front) SMW1868 NSP CS Assy (Surround) SMW1869 NSP CS Assy (Center) SMW1862 NSP CS Assy (Subwoofer) SMW1870 NSP Model Label (FL)(XTW/UC Type) SAN3559 NSP Model Label (FR)(XTW/UC Type) SAN3560 NSP Model Label (SL)(XTW/UC Type) SAN3561 NSP Model Label (SR)(XTW/UC Type) SAN3562 NSP Model Label (C)(XTW/UC Type) SAN3563 NSP Model Label (SW)(XTW/UC Type) SAN3564 NSP Accessary Set SEA1671 Speaker Wire SDS1173 Non Skid Pads SEC1912 Non Skid Pads SEP1240 Polyethylene Bag SHL1296 NSP Screw Set SEA1676 Screw BMZ250P120FNC Polyethylene Bag S0 SHL1314 NSP Bracket Set SEA1677 Wall Bracket SNN1047 Polyethylene Bag S0 SHL1404 Operating Instructions SRD1283 Top Protector SHA2489 Middle Protector SHA2490 Bottom Protector SHA2491 Protection Sheet SHC1821 Packing Case SHG2618 Polyethylene Bag S2 SHL1417 Polyethylene Bag S1 SHL1419
Page 2
3 1 234 1 23 4 C D F A B E S-FCRW2500 Mark No. Description Part No. CS ASSY (Subwoofer) Mark No. Description Part No. CS ASSY (Center) NSP Cabinet SNK2851 Grille SMG1840 NSP Badge 28 SAM1506 NSP Grille Cloth SAS1591 NSP Baffle SMK2852 Speaker Wire SDD1345 Packing (size 4 x 75 mm) SEC1913 In-Put Terminal SKX1089 NSP Acoustic Absorbent (White) SMT1293 NSP Acoustic Absorbent (Black) SMV2198 Speaker K77DU55-51D Screw BPZ35P080FNI Screw BPZ35P120FNI NSP Cabinet SMM2012 Cosmetic Baffle Assy SXG1474 NSP Cosmetic Baffle SNK2842 NSP Badge 37 SAM1507 Damper SEP1305 Packing SEC1911 Speaker wire SDD1344 Speaker A14LU75-53D Screw (for Speaker unit) BYC40P130FZB SCHEMATIC DIAGRAM SDD1345 Full-Range INPUT Red White
