Page 1
2 1 23 4 1234 C D F A B E S-EV9V 15 15 16 17 16 18 10 11 13 12 3 1 2 7 7 668 8 45 9, 14 2.1 PACKING Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: Mark No. Description Part No. PACKING Parts List 2. EXPLODED VIEWS AND PARTS LIST Mark No. Description Part No. NSP 1 Front Speaker (L) SMW1955 NSP 2 Front Speaker (R) SMW1956 NSP 3 Center Speaker SMW1957 NSP 4 Surround Speaker (L) SMW1961 NSP 5 Surround Speaker (R) SMW1962 NSP 6 Subwoofer SMW1963 7Protection Sheet S2 SHC1826 8Protection Sheet S4 SHC1827 9Speaker Cord (for Subwoofer) 439929113167 10 Top Protector 43992936410611 Bottom Protector 439929364107 12 Top Protector 439929364108 13 Bottom Protector 439929364109 14 Non Skid Pad 439929484271 NSP 15 Polyethylene Bag S5 SHL1430 NSP 16 Polyethylene Bag S7 SHL1434 NSP 17 Polyethylene Bag S4 SHL1433 for XJM/E type 18 Packing Case 439929334126 for XJM/NC type 18 Packing Case 439929334138
Page 2
3 1 234 1 23 4 C D F A B E S-EV9V Acoustic Absorbent Back Board 2 1 Model Label 54 Baffle Board 7 6Wrap Board 3 DuctModel Label 4Gasket 87Inner Baffle 1 532 6 Acoustic Absorbent 9 or 10 FRONT SPEAKER Parts List Mark No. Description Part No. 2.2 FRONT SPEAKER 1Speaker A14LU80-53D 2Screw BRZ35P080FTC 3Screw BRZ40P100FTC 4Speaker E52AP39-63D 5Catch SNK29156Rubber Foot VEB1349 7Cosmetic Baffle 439929418935 8Grille Assy 829929752290 for Left channel 9Network Assy 439929113173 for Right channel 10 Network Assy 439929113174 Mark No. Description Part No. 2.3 SUBWOOFER SUBWOOFER Parts List Mark No. Description Part No. 1Speaker A14LR80-51H 2Screw BYC40P200FTC 3Rubber Foot VEB1349 4Input Terminal 439929050801 5Connection Cord 439929110152 6Gasket 439929484260 7Cosmetic Baffle Assy 829929752296
