Page 1
2 1 23 4 1234 C D F A B E S-EV500V NSP Cabinet SMM2021 Grille Assy SMG1849 Name Plate 36 AAM7013 NSP Gasket SEC1954 NSP Double Face Tape SEH1072 NSP Grille Assy SMG1842 NSP Grille Frame SMH1107 NSP Punching Net SNC1206 Cosmetic Baffle Assy SXB1487 NSP Cosmetic Flange SFR1083 NSP Cosmetic Baffle SNK2873 NSP Hexagon Socket Screw SBA1257 Network Assy SWN1750 Gasket SEC1951 Gasket SEC1952 Non Skid Pad SEC1953 Gasket SEC2017 NSP Duct 42.5 SMR1395 Catch SNK2915 Speaker (Woofer) A14LU75-55D Speaker (Tweeter) E52AP39-62D Screw (for Tweeter) BPZ40P060FTC Screw (for Woofer) BPZ40P100FTC Screw (for Cosmetic Baffle) BYC40P200FTC NSP 1 CS Assy SMW1884 for XJM/E type NSP Stanped Label SME3631 NSP Model Label SAN3671 for XJM/NC type NSP Stanped Label SME3632 NSP Model Label SAN3672 2Protector SHA2496 3Protection Sheet S2 SHC1826 NSP 4 Poly Bag S5 SHL1430 for XJM/E type 5Packing Case SHG2651 for XJM/NC type 5Packing Case SHG2652 For Packing Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. CS ASSY Mark No. Description Part No. 4 5 ∅8.5 TAPPING SCREW: M4 SCREW (SBA1257) 10 SCHEMATIC DIAGRAM NetWork Assy (SWN1750) 1, CS ASSY 2.7µF/63V Long LegC INPUT Woofer Black Red WhiteRed Tweeter Short Leg 5 1 2 2 4 3 3
Page 2
3 1 234 1 23 4 C D F A B E S-EV500V PRODUCT APPEARANCE CS ASSY (Front) SMW1885 SMW1886 APPLICATION SET AMP-WF CABLE COLOR COLOR TUBE OF CABLEFRONT(L) FOR S-EV700V FRONT(R) FOR S-EV700V WHITE-WHITE WITH RAY LINE WHITE-WHITE WITH GRAY LINE WHITE RED *THE DIFFERENCE BETWEEN SMW1885 AND 1886. No. PARTS NOTES Num. 1 2 3 6 5 4 7 8 DUCT 42.5 9 10 GASKET NETWORK ASS'Y GRILLE ASS'Y GASKET 11 CABINET NON SKID PAD ----- ----- ---------- COSMETIC FRANGE 2 1 2 1 1 4 1 1 No. PARTS NOTES Num. SPEAKER COSMETIC BAFFLE 14 13 12 15 SPEAKER CATCH SCREW SCREW SCREW HEXAGON SOCKET SCREW 16 17 18 19 20 21 22 23 ADHISIVE ADHISIVE GASKETPYC40P200FTC BPZ40P100FTC BPZ40P060FTC HOT MELT WHITE GLUE 1 14 1 4 3 2 2 4 2g 2g MODEL LABEL(INCLUDED IN SPEAKER SYSTEM SET P/L) White White withGray Line(SMW1885,1886) White (SMW1885,1886) Red 1 10 4 5 9 9 2 3 6 13 14 15 16 17 18 19 20 21 22 23
