Page 1

S-CR59 2 NOTES : Parts marked by Ò NSP Ó are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. PARTS LIST Flange (TW) FRNK-381 Baffle PAV-004 Catch FRMG-182 Badge FRAM-035 Network Assy FRWN-164 Speaker (WF) RC1007A65C5 Speaker (TW) K26EP09-51D Screw (for SP) PPZ30P080FMC Screw (for Cabinet) PPZ40P120FZKSpeaker Cable FRDF-018 Protection Sheet FRHC-043 Packing Case FRHG-285 Protector (Top) FRHA-187 Protector (Bottom) FRHA-188 Operating Instructions FRRD-142 Non-skid Pad FREC-024 Mark No. Description Part No. Mark No. Description Part No. For Packing For S-CR59-C Catch FRMG-182 Badge FRAM-034 Baffle PAV-003 Speaker RC1006A65C3 Screw (for SP) PPZ30P080FMC Screw (for Cabinet) PPZ40P120FZK Mark No. Description Part No. For S-CR59-R
