Pioneer sbd 50 sw service manual
This is the 5 pages manual for pioneer sbd 50 sw service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer sbd 50 sw service manual (Ocr-read)
Page 2
S-BD707SW3 5 678 56 7 8 C D F A B E 2. EXPLODED VIEWS AND PARTS LIST Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of\ the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: 2.1 PACKING 1 4 3 2 2 PACKING Parts List Mark No. Description Part No. NSP 1 Accessories Set SME3951 1-1 Speaker Wire (SW) SDS1223 1-2 Non Skid Pad SEP6042 1-3 Polyethylene Bag SHL1312 2 Protector (B) SHA2656 3 Protection Sheet SHC1895 4 Packing Case(S-BD707SW) SHG2867 Packing Case(S-BD50SW) SHG2876 Packing Case(S-BD808SW) SHG2879
