Extracted text from pioneer sa 6700 service manual (Ocr-read)
Page 1
2 S-A6700 Mark No. Description Part No. Network ASSY (FRWN-159) SCHEMATIC DIAGRAM For Packing Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. NSP Cabinet FRMM-199 NSP Inner Baffle FRNK-374 Grille Assy FRMG-179 Badge FRAM-033 NSP Grille Cloth FRAS-107 NSP Grille Frame FRNK-375 Network Assy FRWN-159 NSP Label Back FRAN-305 Input Terminal FRKX-013 NSP Acoustic Absorbent FRMV-027 Cosmetic Baffle Assy FRXB-037 NSP Cosmetic Baffle FRNK-376 NSP Cosmetic Ring FRNK-373 Speaker(Woofer) B18LU83-53D Speaker(Mid-Range) FD66AP45-54D Screw(for Woofer,Mid-Range) BYC40P160FMCSpeaker Cord FRDD-041 Non-Skid Pads FREC-021 Top Protector FRHA-183 Bottom Protector FRHA-184 Protection Sheet FRHC-049 Packing Case FRHG-277 Woofer Mid-Range I N Red Green WhiteBlue White Blue White Black Tweeter Tweeter 1.5µF/63V WhiteBlue Green Red Black
Page 2
3 S-A6700 PRODUCT APPEARANCE No. 1 2 3 4 5 6 7 8 9 10 Part name Speaker Speaker Cabinet Cosmetic Ring Cosmetic Baffle Grille Assy Input Terminal Label Back Non Skid Pad Acoustic Absorbent Num. 1 1 1 1 1 1 1 1 4 1 Remarks Woofer Mid-Range No. 11 12 13 Part name Screw Staple Network Assy Num. 6 2 1 Remarks 4X16 (for Speaker) to Input Terminal 260 320 245 11 6 54 2 1 (282) 194 9 38 7 13 12 10 to Woofer to Tweeterto Mid-Range
