Pioneer sa 608 service manual

Page 2

Both Model SA-6800 and Model SA-608 have the same basic performance. The major difference
is in appearance, Model SA-6800 being fitmd with wooden side cover and top cover, while
Model SA-608 employs metal cover. The following table is displayed on flue SA-6800 and
SA-608.

MODE L SA-6800
Type Voltage Remarks
KU 120V only U.S.A. model
KC 120V only Canada model
MODE L SA-608
Type Voltage Remarks
KU 120V only U.S.A. model
5 110V, 120V, 220V, and 240V (Switchable) General export model
SIG 110V, 120V, 220V, and 240V (Switchable) U.S. Military model
HE 220V and 240V Europe model
H8 220V and 240V United Kingdom model
HP 220V and 240V Oceania model

o This service manual is applicable to the KU type of the Model SA~6800 and the Model SA-608. When re-
pairing the KC type of the Model SA-6800 and the S, 8/6 types of the Model SA-608, please see the
additional service manual (ART-370), and for HE, HB, HP types of the SA-608, please see the additional
service manual (ART-371).

CONTENTS

1. SPECIFICATIONS ..................... 3 9. SCHEMATIC DIAGRAM, P.C. BOARD

2. FRONT PANEL FACILITIES .............. 4 PAVERNS AND PARTS ST

3. BLOCK OIAGRAM ..................... 6 9- mm ---------------------- 4
4. CIRCUIT DESCRIPTIONS ................ 6 9-2 S°'-""° 0539 ----------------- 5
5. DISASSEMBLY ....................... 8 9'3 P-C' 3° C°"°°°" 939 --------- 3
6. ADJUSTMENTS ....................... 9 9.4 Parts List of P.C. Board Assembles ....... 21
7. PARTS LOCATION .................... 10 10' PACK'NG ------------------------- 23
8. EXPLODED VIEW ..................... 12 1" SUPPLEMENTS FOR MODEL SA'Gos/KU - - - - 23
