Extracted text from pioneer sa 4 sptpm service manual (Ocr-read)
Page 1
2 1 23 4 1234 C D F A B E S-A4SPT-PM 6 8 7 5 No.4: Accessory Set No.1: Accessories Set 2 3 13 (x2 /B, B' side) N o . 11 Speaker System 10 9 12 4 1 N o . NSP 1 Accessories Set SME3671 2Speaker Wire SDS1106 3Polyethylene Bag S1 SHL1252 NSP 4 Accessory Set SME3719 5Polyethylene Bag S2 SHL1295 6Operating Instructions SRD1313 (English, French, German, Italian, Duch, Swedish, Spanish, Portuguese, Russian, Danish, Norwegian, Finnish, Simp-Chinese, Trad-Chinese) NSP Accessories Set SME3672 7Non Skid Pad SEC1964 8Polyethylene Bag S0 SHL1259 9Protector (Top) SHB6027 10 Protector (Bottom) SHB6028 11 Packing Case SHG6220 12 Polyethylene Bag S3 SHL1401 NSP 13 Label Serial SRW1112 2. PARTS LIST 2.1 PACKING NOTES : ÷ Parts marked by NSP are generally unavailable because they are not in our Master Spare Parts List. ÷The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. PACKING Parts List Mark No.Description Part No. NSP 11 Packing Case SHG2743 Packing Case SHG6220 NSP Label for Packing Case - - - - - - Packing Case for China Model Only Mark No.Description Part No.
Page 2
3 1 234 1 23 4 C D F A B E S-A4SPT-PM 392322 28 34 (x4)21 40 30 (x3) 29 42 (x7) 27 33 41 (x4) 26 37 3631 (31) 32 35 38 Arrow view A-A' < BACK VIEW > B: Detail Back Board 29 + : Terminal (Red) Network Assy Black Red White White / Black Transparence Transparence with White Line Red Black Attach the terminals at the angle to specify. A' A B 25 24 23 < Front View > < Back View > No.22 Grille 2.2 SPEAKER SYSTEM NSP 21 Cabinet SMM2036 22 Grille SMG1852 23 Logo SAM1489 NSP 24 Grille Frame SMH1039 25 Catch SNK2584 26 Network Assy SWN1754 NSP Packing SEC1963 NSP Circuit Board SNR1142 NSP 27 Gasket (Tw) SEC1569 NSP 28 Gasket (Wf Side) SEC1576 NSP 29 Damper (Baffle Block) SEP1341 NSP 30 Damper (Tw) SEP1352 NSP 31 Damper (Port) SER1312 32 Input Terminal (Red) SKX6029 33 Input Terminal (Black) SKX6030 34 Catch SLH1072 NSP Acoustic Absorbent (Top,Bottom) SMT1129NSP Acoustic Absorbent (Sides) SMT1130 NSP Acoustic Absorbent SMT1300 (Terminal, Port Sides) NSP Acoustic Absorbent (Port) SMT1301 NSP Acoustic Absorbent (Tw Back) SMT1302 NSP 35 Label Serial SRW1111 NSP 36 Assistant Label (for Label Serial) SRW1114 NSP 37 Model Label SAN3793 NSP 38 Country Label SAN3876 39 Speaker (Woofer) T10ER77-52D 40 Speaker (Tweeter) FADD55-55D 41 Screw (for Network Assy) BYC40P180FTB 42 Screw (for Wf, Tw) SBA1259 SPEAKER SYSTEM Parts List Mark No.Description Part No. Mark No.Description Part No. NSP 37 Model Label SAN3875 Model Label for China Model Only Mark No.Description Part No.
