Page 1

2 S-A370 Mark No. Description Part No. Network ASSY (SWN1617) SCHEMATIC DIAGRAM For Packing Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: PARTS LIST Mark No. Description Part No. NSP Cabinet (L) SMM1871 NSP Cabinet (R) SMM1872 Network ASSY SWN1617 Gasket (for Baffle wide) SEC1446 Gasket (for Baffle height) SEC1447 Cosmetic Baffle ASSY (L) SXB1382 NSP Punching Net SNC1175 NSP Cosmetic Baffle (L) SNK2408 Diaphragm ASSY 20 SXE1092 NSP Ceramic Tweeter SCA1017 NSP Terminal (Red) SKF1034 NSP Terminal (Black) SKF1035 Cosmetic Baffle ASSY (R) SXB1383 NSP Punching Net SNC1175 NSP Cosmetic Baffle (R) SNK2409 Diaphragm ASSY 20 SXE1092 NSP Ceramic Tweeter SCA1017 NSP Terminal (Red) SKF1034 NSP Terminal (Black) SKF1035Top Protector SHA2174 Bottom Protector SHA2175 Protection Sheet SHC1730 Packing Case SHG2232 NSP Polyethylene Bag S5 SHL1230 Mark No. Description Part No. Speaker (Woofer) A14LC83-51D Speaker (Mid-range) E52AP39-57D Screw (for Mid-range) BPZ30P080FMC Screw (for Woofer )BPZ40P100FMC Tapping Screw (for Cosmetic Baffle)SBA1161 NSP Stamped Model Label (L) SME2965 NSP Model Label (L) SAN2755 NSP Stamped Model Label (R) SME2966 NSP Model Label (R) SAN2756 Woofer 2.2µF Midrange I N Tweeter Diaphragm ASSY 20 (In Cosmetic Baffle ASSY) Red White Black Black Black RedRed Red

Page 2

3 S-A370 PRODUCT APPEARANCE 8 9 10 2Gasket Horizontal 2 Gasket Vertical 2 11 12 13 Punching Net 71 4 1 Screw Screw Cabinet (R) Screw (Hexagon socket) Network Assy Speaker Speaker Speaker 1 1 4Model Label (R) 1 1 1 6 5 4 3 2 1Part name Num. No. Remarks Part name Num. No. Remarks 1 Cosmetic Baffle (R) M4x55 M4x10(Woofer) M4x8 (Mid) Woofer Mid Tweeter *This product appearance shows Rch. Lch is symmetrical to center line. 320.5 Silk printing 215 13 11 12 10 9 8 75 4 3 2 1 166 (242) 6
