Pioneer pl 600 service manual

Page 2

MODEL PL-600 (PL-600X) COMES IN SIX VERSIONS DISTINGUISHED AS FOLLOWS:

Typo Voltage Remarks
KCT 120V only Canada model (Without cartridge)
KUT 120V only U.S.A. model (Without cartridge)

HET (PL-GOOX) 220V and 240V (Switchable)

Europe model (Without cartridge)

HBT (P L-GOOX) 220V and 240V (Switchable) United Kingdom model (Without cartridge)
S 110V, 120V, 220V and 240V (Switchable) General export model (Within cartridge)
SIG 110V, 120V, 220V and 240V (SWitchobIO) U.S. Military model (Within cartridge)

For discriptions of the DD. motor and full auto
mechanism employed in this model refer to the
PL-630 service manual (ART-314).

CONTENTS
1. SPECIFICATIONS ..................... 3
2. PANEL FACILITIES .................... 4
3. DISASSEMBLY ....................... 6
4. PARTS LOCATION .................... 9
5. ADJUSTMENT ........................ 11
6. EXPLODED VIEW AND PARTS LIST
6.1 Cabinet ......................... 12
6.2 Tonearm ........................ 15
6.3 DD. Motor ...................... 17
6.4 Packing ......................... 18
7. SCHEMATIC DIAGRAM (KCT, KUT) ........ 19
8. P.C. BOARD CONNECTION DIAGRAM ....... 22
(KCT, KUT)
8.1 Parts List of P.C. Board Assembly
(KUT, KCT) ...................... 25

9. PACKING (SIG, S) ..................... 26
10. SCHEMATIC DIAGRAMS (S, SIG) .......... 27
11. P.C. BOARD CONNECTION DIAGRAM ....... 30

(S, SIG)
11.1 Parts List of P.C. Board Assembly
(8, SIG) ......................... 33
12. PACKING (HET, HBT) .................. 34
13. SCHEMATIC DIAGRAM (PL-600x
(HET, HBT) .......................... 35
14. P.C. BOARD CONNECTION DIAGRAM ....... 38
(NET, HBT)
14.1 Parts List of P.C. Board Assembly
(HET, HBT) ...................... 41
