Pioneer pl 510 a owners manual

Page 2

The PL-SIOA is a high precrsion direct drive turntable designed
for incorporation into a component type stereo music system.
It is recommended that you read these Operating Instructions
completely before using the turntable.

PL-51OA FEATURES

DC Servo Motor Direct Drive System

A control circuit consisting of three Hall effect semiconductors
precisely detects position and regulates motor winding current of
the brushless DC motor. Together with the precision machined
high-inertia platter, this ensures superb rotational characteristics,
including SN ratio of more than 68dB (DlN-B) and wow and
flutter of less than 0.03% (WRMS).

Automatic Control Circuit and Precise Speed Adjustment

Motor rotation is maintained at a constant rate by an electronic
control circuit. This assures precise and stable operation without
influence from fluctuations in power supply voltage, ambient
temperature or humidity. lndependent speed adjustment controls
are provided for 334/3 and 45 rpm, together with a stroboscope
inscribed on the outer rim of the platter. By observing the
stroboscope as it is illuminated by the built-in strobe light, precise
speed adjustment can be performed in the range oi t2%.

CONTENTS High Sensitivity Statically Balanced Tonearm

Angular contact bearings in the tonearm pivots offer significant

PL510A Features -------------- 2 advantages over precious bearing types in terms of low friction
Attaching the Cartridge .......... 3 and vibration. The carefully engineered design provides both
enhanced stability and long term reliability. Anti-skating and
Assembly Steps """"""""" 4 lateral balance mechanisms are also incorporated for improved
Component Locations ........... 5 "kinfl Pe'formance-
Tonearm Adjustments ........... 6 Designed With Attention to Detail
, . . , . New technology is incorporated in the base, and insulator to
Stereo Amplifier Connections """ 7 achieve advanced sound quality and SN ratio. Mineral Solid, a
Dust Cover .................... 7 newly developed material, forms the base plate, while the acoustic
Panel Facilities ................. 8 suspension'insulator combines butyhrubber, natural rubber and
air suspension to obtain a high howling margin.
I ration """""""""""" 9 Straight Line Control Panel Layout
Care Of Your Tumtahle ---------- 10 Controls and switches are grouped in a straight line at the right
Conditions Frequently Mistaken side of the panel, so operation is thus concise and easy to perform.
for Malfunctions 10 Additional convenient features are free stop dust cover hinges
. . . """ and a spare headshell stand. 'lhe professional, yet bold, appearance
Spec1ftcattons .................. 11 of the PL-SlOA adds a fascinating contemporary accent to listening

room decor.
