Pioneer pl 500 x service manual
This is the 19 pages manual for pioneer pl 500 x service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer pl 500 x service manual (Ocr-read)
Page 2
MODEL PL-500X COMES IN TWO VERSIONS DISTINGUISHED AS FOLLOWS:
TYPO Voltage Remarks
HET 220V and 240V (Switchabie) Europe model (Without cartridge)
HBT 220V and 240V (Switchable) United Kingdom model (Without cartridge)
CONTENTS
1. SPECIFICATIONS ..................... 3
2. PANEL FACILITIES .................... 4
3. DISASSEMBLY
3.1 Cabinet ......................... 6
3.2 Tonearm ........................ 7
4. ADJUSTMENTS
4.1 0.0. Motor Operation Adjustment ....... 8
4.2 Mechanism Adjustments .............. 9
5. PACKING
8. EXPLODED VIEWS AND PARTS LIST
6.1 Cabinet ......................... 1 1
8.2 Subpanel ........................ 14
6.3 0.0. Motor ...................... 16
7. SCHEMATIC DIAGRAM ................. 17
8. 9.0. BOARD CONNECTION DIAGRAM
8.1 Parts List of P.C. Board Assembly ....... 21
For description of the D. D. motor, refer to the
PL-630 service manual (ART-314) and for full auto
mechanism, refer to the PL-3000 service manual
(ART-350).
