Pioneer pl 12 e service manual

Page 2

PL-I BE

1. SPECIFICATIONS

MOTOR AND TURNTABLE

Motor ..................... 4-pole synchronous motor
Turntable drive ............... Belt-driven
Speed ..................... Two speeds, 33-1/3, 45 rpm
Wow and flutter .............. 0.1% (WRMS) or less
S/N ...................... 47dB or more
Turntable platter ............. 12 (30cm) diameter die-cast aluminum alloy
TONEARM
Tonearm ................... Static balance type, pipe arm
Effective arm length ........... 22.10m
Furnished cartridge ............ PIONEER PC-12
(Moving magnet type)
MISCELLANEOUS
Power requirements ............ AC 220/240V, 1 10/130V,
60H: or 50Hz
Power consumption ............ 10W (MAX)
Dimensions ................. 430(W) X 160.5(H) x 349(Dlmm
(17 x 65/16 x 13-3/4 in.)
Weight .................... 7.5kg (16 lb. 8 oz.)
ACCESSORIES
Lubricator ............ 1 EP adaptor ........... 1
Screwdriver ........... 1 Motor pulley .......... 1
Sub counterweight ...... 1 Operating Instructions . . .1

FURNISHED CARTRIDGE MODEL PC-12

Type ..................... Moving magnet type
Construction ................ Super permalloy shield
Frequency response ............ 20~23,000Hz

Output voltage ............... 4mV (1kHz 50mm/s)
Channel separation ............ 23dB over (at 1kHz 10mm/s)
Load impedance .............. 30kQ~100kQ

Impedance .................. 2.5kSZ (at 1kHz)

Static compliance ............. 15.0 x 106 cm/dyn
Dynamic compliance ........... 7.5 x 10'6 cm/dyn

Stylus point ................. 0.6 mil diamond

Stylus for replacement .......... Pioneer stylus model PN-12
Tracking force (stylus pressure) . . . . 2.7~3.Sg

Weight .................... 5.59

All conforms to EIA specification.

NOTE: Specifications and the design subject to possible
modification without notice due to improvements.
