Page 1
2 1 23 4 1234 C D F A B E PDP-S50 1.REASSEMBLY AND DISASSEMBLY PRECAUTIONS The grille ASSY is attached to the baffle using double-sided self-adhesive tape. To avoid damaging the cabinet, work with the speaker on top of a blanket or similar, face the grille ASSY upward. There is slot in the lower part of the speaker. To detach it, first push up the lower part by inserting a screwdriver(-) into slot. Taking care not to damage the grille and baffle, lift the grille a little bit at a time with hand. Though they are attached tight at center position, do more cafully. *Be careful not to damage the grille ASSY by bending too much. Grille ASSY Baffle Grille ASSY Baffle LOCATIONS TO FIX DOUBLE-SIDED SELF-ADHESIVE TAPE Tape (SEH1077 x2) Grille ASSY (Back Side)Baffle Tape (SEH1094 x2) Tape (SEH1088 x2) (32) GRILLE ASSY Slot Screwdriver(-) Grille ASSY Baffle When reattaching the grille ASSY, use double-sided self-adhe- sive tape in the locations shown in the diagram and press the grille ASSY into place.
Page 2
3 1 234 1 23 4 C D F A B E PDP-S50 The woofer is attached to the baffle by 4 internal screws. To detach it, first remove the baffle from cabinet by unfastening external 16 screws. Then unfasten those screws. When attach- ing it, face its plus terminal downward. When changing it, stick the felt(SED1123 4pcs.) on the speci- fied position of the woofer frame. 16 SCREWS (BPZ40P100FTB) Baffle The tweeter is attached to the baffle by 2 internal screws. To detach it, first remove the baffle from cabinet. Then unfasten those screws. When attaching it, face its plus terminal (bigger terminal) rightward. LOCATIONS TO FIX FELT Felt (SED1123) Felt (SED1123)
