Pioneer pdps 17 lr service manual
This is the 2 pages manual for pioneer pdps 17 lr service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer pdps 17 lr service manual (Ocr-read)
Page 1
2 1 23 4 1234 C D F A B E PDP-S17-LR 1. CONTRAST OF MISCELLANEOUS PARTS 7 CONTRAST OF TABLE PDP-S17-LR/XIN/WL5 and PDP-S17-LR/XIN/WL are constructed the same except for the following: Ref.Part No. No.Mark Symbol and DescriptionPDP-S17-LR PDP-S17-LR Remarks XIN/WL XIN/WL5 Input Terminal KKX1015 SKX1097 Metal Reinforce SNA1404 SNA1442 Speaker A142CU61-53F A142CU60-51F TwFK26AP02-69F FK26AP13-55F For Packing NSP Accessory Set SEA1574 SEA1718∗1 NSP Accessory Set SME3272 SME3713∗1 NSP Operating Instructions Set SME3458 SME3714∗1 Packing Case SHG2534 SHG2702 Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. NOTES: NOTES : ∗1: Although the part numbers are different in PDP-S17-LR/XIN/WL5 and PDP-S17-LR/XIN/WL, they have the same service parts.
