Page 1

PIONEER

The future of sound and vislo.

Sefiice
(714211111511

_ . ORDER NO.
----- ARP1665

MULTl-PLAY COMPACT DISC PLAYER

D-ZBE

MODEL PD-282M HAS FOUR VERSIONS:

Type Pow nquiromlnl Export destination
HEM AC 220V, 240V (swilchablsi European conlinem
HE AC 220V, 240V (switchable)' UniIed Kingdom
SD AC HOV, I20V < 127V, 220V, 240V (switchable) Kingdom of Saudi Arabia and genetal market
HP AC 220V, 240V (swilchabIeP Australia
KU AC 120V only U.S.A.

" Change the connection wire from Power switch board assembly to Transformer board assembly,

CONTENTS

1. SAFETY INFORMATION .............. 2 7. P.C. BOARDS CONNECTION DIAGRAM 19
2. SPECIFICATIONS .................... 4 8. ELECTRICAL PARTS LIST ............. so
3. PANEL FACILITIES .................. 5 9. ADJUSTMENTS . . .I ............. 33
4. PACKING .......................... a REGLAGE ..I ...................... 44
5. EXPLODED VIEWS AND PARTS LIST 9 AJUSTE ........................... 55
6. SCHEMATIC DIAGRAM ............... 15 10. FOR HB,HP AND SD TYPES ........... as

PIONEER ELECTRONIC CORPORATION 4-1. Meguro 1-Chome, Meguro»ku. Tokyo 153. Japan

PIONEER ELECTRONICS SERVICE INC. PO Box 1760, Long Beach. California 90501 U.S.A.

PIONEER ELECTRONICS OF CANADA, INC. 505 Cochrane DrIve, Markham. Ontario L3H 8E3 Canada

PIONEER ELECTRONIC [EUROPE] N.VL Keelberglaan 1. 2740 Beveren. Belgium

PIONEER ELECTRONICS AUSTRALIA PTY. LTD. 178-184 Boundary Road. Braeside, Victoria 3195. Australia TEL: [03} 580-99

© PIONEER ELEcTRONIc CORPORATION 1989 MI MN. ,989 Pmdm W"

Page 2

-282M

1. SAFETY INFORMATION

'(FOR USA MODEL ONLY)

1. SAFETY PRECAUTIONS

tinued protection of the customer and service technicians
LEAKAGE CURRENT CHECK

Measure leakage current to a known earth ground (water
pipe, conduit, etc.) by connecting a leakage current tester
such as Simpson Model 2292 or equivalent between the
earth ground and all exposed metal parts of the appliance
(input/output terminals, screwheads, metal overlays, con-
trol shaft, etc.), Plug the AC line cord of the appliance
directly into a 120V AC 60Hz outlet and turn the AC
power switch on. Any current measured must not exceed
_ 0.5mA.

Reading should
not be above
0.5mA

L
cu rrent
tester


Device
under
test


Test all
exposed metal
»surfaces

9 2vwire cord

® Also test With
plug reversed T Earth
iUSJHQ AC adapter ground
plug as required)

AC Leakage Test

The following check should be performed for the con.

ANY MEASUREMENTS NOT WITHIN THE LIMITS OUT-
LINED ABOVE ARE INDICATIVE OF A POTENTIAL
SHOCK HAZARD: AND MUST BE CORRECTED
BEFORE RETURNING THE APPLIANCE To THE
CUSTOMER.

2.PRODUCT SAFETY NOTICE

Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are often
not evident from visual inspection nor the protection af-
forded by them necessarily can be Obtained by using re-
placement components rated for Voltage, wattage, etc. Re-
placement parts which have these special safety charac-
teristics are identified in this Service Manual.

Electrical components having such features are identified
by marking with a A on the schematics and on the parts
list in this Service Manual.

The use of a substitute replacement component which
does not have the same safety characteristics as the
PIONEER recommended replacement one, shown in the
parts Iist'in this Service Manual, may create shock, fire, or
other hazards.

Product Safety is continuously under review and new
instructions are issued from time to time, For the latest
information, always consult the current PIONEER Serv-
ice Manual. A subscription to, or additional copies of,
PIONEER Service Manual may be obtained at a nominal
Charge from PIONEER. '

(FOR EUROPEAN MODEL ONLY)

-VAROITUS!

LAITE SISALTAA LASERDIODIN, JOKA
LAHETTAA NAKYMATONTA, SILMILLE
VAARALLISTA INFRAPUNASATEILYA
LAITTEEN SISALLA 0N LASERDIODIN
LAHEISYYDESSA KUVAN I. MUKAINEN
VAFIOITUSMERKKI.

LASER
Kuva 1

, Lasersateilyn
varoitusmerkki

ADVERSEL:
USYNLIG LASERSTRALING VED ABNING
NAH SlKKERHEDSAFBRYDERE ER UDE
AF FUNKTION UNDGA UDSAETTELSE
FOR STRALING.

_ VIKTIGT
APARATEN INNEHALLER LASER Av HOGRE
KLASS AN 1. INGREPP I APPARATEN BOR
GORAS AV SPECIELLT UTBILDAD PERSONAL.

WARNINCI
DEVICE INCLUDES LASER DIODE WHICH
EMITS INVISIBLE INFRARED RADIA»
TION WHICH IS DANGEROUS T0 EYES.
THERE ISAWARNING SIGN ACCORDING LASER
T0 PICTURE I INSIDE THE DEVICE
CLOSE To THE LASER DIODE.

Picture 1

Warning sign for
laser radiation

IMPORTANT
PIONEER COMPACT DISC PLAYER APPARA-
TUS CONTAINS LASER OF HIGHER ,CLASS
THAN 1, SERVICING OPERATION OF THE AP-
PARATUS SHOULD BE DONE BY A SPECIALLY
INSTRUCTED PERSON.
