Pioneer mis 22 service manual

This is the 2 pages manual for pioneer mis 22 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 2
pioneer mis 22 service manual

Extracted text from pioneer mis 22 service manual (Ocr-read)


Page 1

M-IS22 2 1. CONTRAST OF MISCELLANEOUS PARTS CONTRAST TABLE Part No. Ref. No. Mark Symbol and Description M-IS22 M-IS22 Remarks /MYXJ /NKXJ PACKING SECTION P3- 1Power Cord ADG1154 DDG1086 P3- 8 Packing Case XHD3170 XHD3184 EXTERIOR SECTION P5-15 Rear Panel XNC3107 XNC3138 M-IS22/NKXJ and MYXJ are constructed the same except for the following : Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screws adjacent to mark on product are used for disassembly. Reference Nos. indicate the pages and Nos. in the service manual for the base model. NOTES:
