M-IS21 2 1. CONTRAST OF MISCELLANEOUS PARTS Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screws adjacent to mark on product are used for disassembly. Reference Nos. indicate the pages and Nos. in the service manual for the base model. NOTES: CONTRAST TABLE Part No. Ref. No. Mark Symbol and Description M-IS21 M-IS21 Remarks /MYXJ /MAMXQ PACKING SECTION P3- 1 Side Pad AL AHA7238 AHA7317 P3- 2 Side Pad AR AHA7239 AHA7318 P3- 3 Packing Case AHD7747 AHD7954 EXTERIOR SECTION P5-12 DC FAN Motor AXM7003 AXM7014 P5-14 Rear Panel ANC7823 ANC7985 P5-26 Top Panel AAN7192 AAN7202 P5-27 Front Panel A AMB7564 AMB7740 P5-28 Side Bonnet ANE7242 ANE7265 Label (REAR) Not used VRW1739 *1 M-IS21/MAMXQ and MYXJ are constructed the same except for the following : *1 Stick Label on the Rear Panel.
