HTV-C2 2 1. CONTRAST OF MISCELLANEOUS PARTS NOTES :ÖParts marked by Ò NSP Ó are generally unavailable because they are not in our Master Spare Parts List. ÖThe mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing,be sure to use parts of identical designation. ÖReference Nos. indicate the pages and Nos. in the service manual for the base model. ÖScrew adjacent to ° mark on the product are used for disassembly. ÖWhen ordering resistors, first convert resistance values into code form as shown in the following examples. Ex. 1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J = 5%, and K = 10%). 560 W = 56 ´ 10 1 = 561 ...................................................RD1/4PU 5 6 1 J 47k W = 47 ´ 10 3 = 473 ..................................................RD1/4PU 4 7 3 J 0.5 W = R50 ......................................................................RN2H å 5 0 K 1 W = 1R0 .........................................................................RS1P 1 å 0 K Ex. 2 When there are 3 effective digits (such as in high precision metal film resistors). 5.62k W = 562 ´ 10 1 = 5621...........................................RN1/4PC 5 6 2 1 F Part No. Remarks AUXJ AUXJ ACXJ Ref. No.MarkSymbol and Description PACKING P3-8 Operating Instructions (French) Not used Not used ARC7200 P3-10 NSP Warranty Card ARY1051 ARY1051 ARY1075 P3-11 Remote Control Unit (CU-HTV001) AZN7713 Not used Not used P3-12 NSP Remoto Control Unit (CU-HTV001) AXD7157 Not used Not used P3-12 NSP Remoto Control Unit (CU-HTV002) Not used AXD7160 AXD7160 P3-13 Battery Cover RZN1156 AZN2256 AZN2256 P3-15 NSP Dry Cell battery (R6P, AA) VEM-013 Not used Not used P3-15 NSP Alkali Ne Battery (LR03, AAA) Not used AEX1006 AEX1006 P3-21 Packing Case AHD7574 AHD7590 AHD7590 EXTERIOR P5-8 Rear Panel ANC7655 ANC7661 ANC7661 HTV-C1 HTV-C2 CONTRAST TABLE HTV-C2/AUXJ, ACXJ and HTV-C1/AUXJ are constructed the same except for the following :
