Pioneer htv 1 service manual
This is the 2 pages manual for pioneer htv 1 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer htv 1 service manual (Ocr-read)
Page 1
HTV-1 2 EXPLODED VIEWS AND PARTS LIST Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. The mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. Screws adjacent to mark on product are used for disassembly. NOTES: Mark No. Description Part No. 1 Corner Pad Assy BTM 261136 (SHA2105) 2 Corner Pad Assy TOP 261141 (SHA2106) 3 Card Board (SHB1068) 257830 4 Packing Case See Contrast table (2) 5 Poly. Bag (SHL1187) 235201 NSP 6 Coaded Label (SRM1069) 244126 (1) PACKING PARTS LIST 2 (2/2) 1 (2/2) 1 (1/2)2 (1/2) 3 5 HTV-SW1 HTV-C1 4 6 7 PACKING (2) CONTRAST TABLE HTV-1/KUXC and HTV-1/KCXC are constructed the same except for the following: Mark KUXC type KCXC type 4 Packing Case (SHG2065) 254900 Not used 4 Packing Case (SHG2080) Not used 257865 Part No. Remarks Symbol and Description No.
