Extracted text from pioneer gmx 422 service manual (Ocr-read)
Page 1
2 GM-X422, GM-X322 2. EXPLODED VIEWS AND PARTS LIST 2.1. PACKING 1 Contain Box See Contrast table (2) 2 Carton See Contrast table (2) 3 Protector HHP0020 4 Polyethylene Bag HEG0010 5 Screw(x4) BYC40P180FZK6 Polyethylene Bag HEG0011 7 Terminal(x8) See Contrast table (2) 8 Cord Assy See Contrast table (2) 9-1 Owners Manual See Contrast table (2) 9-2 Owners Manual See Contrast table (2) * 9-3 Warranty Card HRY1070 * 9-4 Caution Card See Contrast table (2) * 9-5 Card See Contrast table (2) (1) PACKING SECTION PARTS LIST Mark No. Description Part No. Mark No. Description Part No. NOTE: - Parts marked by *are generally unavailable because they are not in our Master Spare Parts List. - Screws adjacent to Ñmark on the product are used for disassembly. Fig. 1
Page 2
3 GM-X422, GM-X322 (2) CONTRAST TABLE GM-X422/X1R/UC, GM-X422/X1R/ES, GM-X422/X1R/EW and GM-X322/X1R/UC are constructed the same except for the following: Part No. GM-X422 GM-X322 Mark No. Symbol and Description X1R/UC X1R/ES X1R/EW X1R/UC 1 Contain Box HHL0134 HHL0135 HHL0136 HHL0133 2 Carton HHG0134 HHG0135 HHG0136 HHG0133 7 Terminal(x8) HKC0001 HKC0003 HKC0003 HKC0003 8 Cord Assy Not used HDE4419 HDE4419 Not used 9-1 Owners Manual HRD0048 HRD0045 HRD0047 HRD0046 9-2 Owners Manual Not used HRD0049 Not used Not used * 9-3 Warranty Card HRY1070 Not used HRY1087 Not used * 9-4 Caution Card HRP0006 Not used Not used Not used * 9-5 Card Not used Not used Not used ARY1048 -Owner's Manual Model Part No. Language GM-X422/X1R/UC HRD0048 English, French GM-X422/X1R/ES HRD0045 English, Spanish HRD0049 Arabic, Portuguese(B) GM-X422/X1R/EW HRD0047 English, French, German, Dutch, Spanish, Italian GM-X322/X1R/UC HRD0046 English, French
