Pioneer gmx 252 service manual
This is the 21 pages manual for pioneer gmx 252 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer gmx 252 service manual (Ocr-read)
Page 1
PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE INC.P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A. PIONEER EUROPE NVHaven 1087 Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE.LTD.253 Alexandra Road, #04-01, Singapore 159936 C PIONEER CORPORATION 2000 K-ZZS. NOV. 2000 Printed in Japan ORDER NO. CRT2614 BRIDGEABLE POWER AMPLIFIER GM-X352 X1R/UC,EW,ES Service Manual CONTENTS 1. SAFETY INFORMATION ............................................2 2. EXPLODED VIEWS AND PARTS LIST ......................2 3. SCHEMATIC DIAGRAM .............................................6 4. PCB CONNECTION DIAGRAM..................................8 5. ELECTRICAL PARTS LIST ........................................126. ADJUSTMENT .........................................................14 7. GENERAL INFORMATION.......................................15 7.1 DISASSEMBLY ..................................................15 8. OPERATIONS AND SPECIFICATIONS ....................16 GM-X352/X1R/EW
Page 2
2 GM-X352 2. EXPLODED VIEWS AND PARTS LIST 2.1 PACKING 1. SAFETY INFORMATION -GM-X352/X1R/UC CAUTION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so and refer the repair to a qualified service technician. W ARNING This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to cause cancer, birth defects or other reproductive harm. Health & Safety Code Section 25249.6 - Proposition 65
